Fluke 1760 [97/110] W warning
![Fluke 1760 [97/110] W warning](/views2/1005066/page97/bg61.png)
Options and Accessories
Accessories 6
6-19
Safety Standards
• IEC/EN 61010-1 2
nd
edition
• IEC/EN 61010-2-032
• IEC/EN 61010-031
EMC Standards
EN 61326 –1: 1997/A1: 1998.
W Warning
Wear high voltage protection gloves, and switch off the
conductors and ensure that the potential is zero.
Utilize the Flexi current sensor only at 600 V rms or dc to
ground and frequencies below 1 kHz.
Accuracy (Typical, for 50/60 Hz)
Linearity, error in % of measured value, primary current in A:
