Standard Voltage Probes for AC and DC
Temperature coefficient: 100 ppm/K
Aging: <0.05 %/year
All voltage sensors are suitable for DC for DC and AC up to 5 kHz
TPS Voltage Probe
for 1760
PN
V
nom
Range
V rms
max.
overload
continuous
Input
resistance
1
Intrinsic
Uncertainty
10 V
2540636 10 V 0,1-17 V 100 V 16 kΩ 0.15 % of rdg
± 8 mV
100 V
2540624 100 V 1-170 V 1000 V 8.5 MΩ 0.15 % of rdg
± 80 mV
400 V
2540660 400 V 4-680 V 1000 V 8,5 MΩ 0.15 % of rdg
± 0.32 V
600 V 2540697 600 V 10-1000 1000 V 8.5 MΩ 0.1 %
2
1000 V 2540649 1000 V 10-1700 2000 V 13 MΩ 0.1 %
3
1
between red and black connector
2
sensor + basic unit 0.1 % of Udin = 230 V P-N in accordance with IEC61000-4-30 Class A
3
sensor + basic unit 0.1 % of Udin = 480 V and 600 V P-N in accordance with IEC61000-4-30 Class A
TPS Voltage Probe
for 1760
PN
Transient
Range
1
Transient
uncertainty
Max. Voltage to earth
Overvoltage category
10 V 2540636 --- --- 300V CATII
100 V 2540624 50-6000V 5 % 600V CATIV
400 V 2540660 50-6000V 5 % 600V CATIV
600 V 2540697 50-6000V 5 % 600V CATIV
1000 V 2540649 50-6000V 5 % 1000V CATIII / 600 V CAT IV
1
signal duration <1ms
