1760
Users Manual
6-6
Shunt Resistors for AC and DC Currents
Model No.
Product
No
Type Range
Peak
Current
for
Sinusoidal
Currents
Intrinsic
Uncertainty
(>1 % of
range)
Frequency
Range
Operating
Voltage
Phase Error
TPS
SHUNT
20 MA
PN
2540553
SHUNT
20 mA
0 – 55 mA 77.8 mA
Imax=1.5 A
0.2 % DC 3.0 kHz 300 V
CAT II
0.1 °
Errors in % of measuring range at 23 °C ± 2 K, for 48 – 65 Hz.
Phase angle error at nominal current.
I
max
maximum current without time limit.
Other Accessories
Product Description/technical specifications Product- No.
Transport case For Instrument and accessories 2540414
Safety adapter With quick-break fuse of 100 kA circuit-breaking capacity 2540530
2 A quick-break fuse With 100 kA circuit-breaking capacity 2540509
Battery pack Replacement battery pack 2540406
Current Clamp 1 A/10 A AC
This current probe has been designed for non intrusive, accurate measurements of small
AC currents. Using latest technologies (internal memory for calibration data) provides
current ranges from 0.01 A up to 10 A. The measurement range can be selected in the PQ
Analyze software: IAC1 or IAC10.
Electrical Characteristics
Nominal current In: 1 A/10 A AC rms
Measuring ranges: 0.01 A – 1 A or 0.1 A – 10 A
Crest factor: < 3
Peak current: 3.7 A/37 A
Max. non destructive current: Up to 100 A rms
Conductor position influence: < 0.5 % of range for 50/60 Hz
Error due to adjacent conductor: ≤ 15 mA/A for 50 Hz
Phase error (to reference conditions): < ±0.5 degrees
Frequency range (clamp without the
instrument):
40 Hz – 10 kHz (−3 dB)
Temperature coefficient: 0.015 % of range/ °C
Safety: 300 V CAT IV, type A sensor, pollution
degree 2
