Danfoss VLT Midi Drive FC-280P4K0 [104/136] Midi drive fc 280
![Danfoss VLT Midi Drive FC-280P2K2 [104/136] Midi drive fc 280](/views2/1557234/page104/bg68.png)
37-13 Pos. PID Output Clamp
Range: Function:
1000* [1 -
10000 ]
This parameter clamps the total output of
the PID. A setting of 1000 corresponds to
100% of parameter 32-80 Maximum Allowed
Velocity.
37-14 Pos. Ctrl. Source
Selects the control source for positioning control.
Option: Function:
[0] * DI
[1] FieldBus
37-15 Pos. Direction Block
Use this parameter to congure whether to block a direction,
and the direction to be blocked.
Option: Function:
[0] * No Blocking
[1] Block Reverse
[2] Block Forward
37-17 Pos. Ctrl Fault Behaviour
This parameter determines the behavior of the frequency
converter after a fault is detected.
Option: Function:
[0] * Ramp Down&Brake
[1] Brake Directly
37-18 Pos. Ctrl Fault Reason
READ-ONLY PARAMETER: The current fault reason of the alarm.
POSITION CTRL FAULT is shown in this parameter.
Option: Function:
[0] * No Fault
[1] Homing Needed
[2] Pos. HW Limit
[3] Neg. HW Limit
[4] Pos. SW Limit
[5] Neg. SW Limit
[7] Brake Wear Limit
[8] Quick Stop
[9] PID Error Too Big
[12] Rev. Operation
[13] Fwd. Operation
[20] Can not nd home position
37-19 Pos. New Index
Range: Function:
0* [0 - 255 ] The currently latched index number.
Parameter Descriptions
VLT
®
Midi Drive FC 280
102 Danfoss A/S © 03/2016 All rights reserved. MG07C202
