5.2.11 10-** CAN Fieldbus
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
10-0* Common Settings
10-01 Baud Rate Select [20] 125 Kbps 1 set-up TRUE - Uint8
10-02 Node ID 127 N/A 1 set-up TRUE 0 Uint8
10-05 Readout Transmit Error Counter 0 N/A All set-ups TRUE 0 Uint8
10-06 Readout Receive Error Counter 0 N/A All set-ups TRUE 0 Uint8
10-3* Parameter Access
10-31 Store Data Values [0] O All set-ups TRUE - uint8
10-33 Store Always [0] O 1 set-up TRUE - Uint8
5.2.12 12-** Ethernet
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
12-0* IP Settings
12-00 IP Address Assignment [10] DCP 1 set-up TRUE - Uint8
12-01 IP Address 0 N/A 1 set-up TRUE 0 OctStr[4]
12-02 Subnet Mask 0 N/A 1 set-up TRUE 0 OctStr[4]
12-03 Default Gateway 0 N/A 1 set-up TRUE 0 OctStr[4]
12-04 DHCP Server 0 N/A 1 set-up TRUE 0 OctStr[4]
12-05 Lease Expires 0 N/A All set-ups TRUE 0 TimD
12-06 Name Servers 0 N/A 1 set-up TRUE 0 OctStr[4]
12-07 Domain Name 0 N/A 1 set-up TRUE 0 VisStr[48]
12-08 Host Name 0 N/A 1 set-up TRUE 0 VisStr[48]
12-09 Physical Address 0 N/A 1 set-up TRUE 0 VisStr[17]
12-1* Ethernet Link Parameters
12-10 Link Status [0] No Link All set-ups TRUE - Uint8
12-11 Link Duration Size Related All set-ups TRUE 0 TimD
12-12 Auto Negotiation [1] On 1 set-up TRUE - Uint8
12-13 Link Speed [0] None 1 set-up TRUE - Uint8
12-14 Link Duplex [1] Full Duplex 1 set-up TRUE - Uint8
12-8* Other Ethernet Services
12-80 FTP Server [0] Disabled 1 set-up TRUE - Uint8
12-81 HTTP Server [0] Disabled 1 set-up TRUE - Uint8
12-82 SMTP Service [0] Disabled 1 set-up TRUE - Uint8
12-89 Transparent Socket Channel Port 4000 N/A 1 set-up TRUE 0 Uint16
12-9* Advanced Ethernet Services
12-90 Cable Diagnostic [0] Disabled 1 set-up TRUE - Uint8
12-91 Auto Cross Over [1] Enabled 1 set-up TRUE - Uint8
12-92 IGMP Snooping [1] Enabled 1 set-up TRUE - Uint8
12-93 Cable Error Length 0 N/A 1 set-up TRUE 0 Uint16
12-94 Broadcast Storm Protection -1 % 1 set-up TRUE 0 Int8
12-95 Broadcast Storm Filter [0] Broadcast only 1 set-up TRUE - Uint8
12-96 Port Cong Size Related 1 set-up TRUE - Uint8
12-98 Interface Counters 4000 N/A All set-ups TRUE 0 Uint32
12-99 Media Counters 0 N/A All set-ups TRUE 0 Uint32
Parameter Lists Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 115
