![Danfoss VLT Midi Drive FC-280P4K0 [95/136] 84 comm option stw](/img/pdf.png)
Danfoss VLT Midi Drive FC-280P4K0 [95/136] 84 comm option stw
![Danfoss VLT Midi Drive FC-280P4K0 [95/136] 84 comm option stw](/views2/1557234/page95/bg5f.png)
16-84 Comm. Option STW
Range: Function:
0* [0 - 65535 ] View the extended eldbus communication
option status word. For more information, refer
to the relevant eldbus manual.
16-85 FC Port CTW 1
Range: Function:
1084* [0 -
65535 ]
View the 2-byte control word (CTW) received
from the bus master. Interpretation of the
control word depends on the eldbus option
installed and the control word prole
selected in parameter 8-10 Control Word
Prole.
16-86 FC Port REF 1
Range: Function:
0* [-32768 - 32767 ] View the last received reference from the
FC port.
16-90 Alarm Word
Range: Function:
0* [0 - 0xFFFFFFFFUL ] View the alarm word sent via the serial
communication port in hex code.
16-91 Alarm Word 2
Range: Function:
0* [0 - 0xFFFFFFFFUL ] View the alarm word 2 sent via the
serial communication port in hex code.
16-92 Warning Word
Range: Function:
0* [0 - 0xFFFFFFFFUL ] View the warning word sent via the
serial communication port in hex code.
16-93 Warning Word 2
Range: Function:
0* [0 - 0xFFFFFFFFUL ] View the warning word 2 sent via the
serial communication port in hex code.
16-94 Ext. Status Word
Range: Function:
0* [0 - 0xFFFFFFFFUL ] Returns the extended status word sent
via the serial communication port in
hex code.
16-95 Ext. Status Word 2
Range: Function:
0* [0 - 0xFFFFFFFFUL ] Returns the extended status word 2
sent via the serial communication port
in hex code.
16-97 Alarm Word 3
Range: Function:
0* [0 - 0xFFFFFFFFUL] Shows the alarm word 3 sent via the
serial communication port in hex code.
Parameter Descriptions Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 93
4 4
