8-43 PCD Read Conguration
Select the parameters to be assigned to the PCDs of the
telegrams. The number of available PCDs depends on the
telegram type. PCDs contain the actual data values of the
selected parameters.
Option: Function:
[23] [1652] Feedback [Unit]
[24] [1660] Digital Input 18, 19, 27, 29,
32, 33
[25] [1661] Terminal 53 Switch Setting
[26] [1662] Analog Input 53(V)
[27] [1663] Terminal 54 Switch Setting
[28] [1664] Analog Input 54
[29] [1665] Analog Output 42 [mA]
[30] [1671] Relay Output [bin]
[31] [1672] Counter A
[32] [1673] Counter B
[33] [1690] Alarm Word
[34] [1692] Warning Word
[35] [1694] Ext. Status Word
8-50 Coasting Select
Option: Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
[0] Digital
input
Activates coasting command via a digital input.
[1] Bus Activates coasting command via the serial
communication port or eldbus option.
[2] Logic AND Activates coasting command via the eldbus/
serial communication port and 1 extra digital
input.
[3] * Logic OR Activates coasting command via the eldbus/
serial communication port or via 1 of the
digital inputs.
8-51 Quick Stop Select
Select the trigger for the quick stop function.
Option: Function:
[0] Digital input
[1] Bus
[2] Logic AND
[3] * Logic OR
8-52 DC Brake Select
Option: Function:
Select control of the DC brake via the terminals
(digital input) and/or via the eldbus.
NOTICE
When parameter 1-10 Motor Construction is
set to [1] PM non-salient SPM, only
selection [0] Digital input is available.
8-52 DC Brake Select
Option: Function:
[0] Digital
input
Activates DC brake command via a digital input.
[1] Bus Activates DC brake command via the serial
communication port or eldbus option.
[2] Logic
AND
Activates DC brake command via the eldbus/
serial communication port and additionally via 1
of the digital inputs.
[3] * Logic OR Activates DC brake command via the eldbus/
serial communication port or via 1 of the digital
inputs.
8-53 Start Select
Option: Function:
Select the trigger for the start function.
[0] Digital
input
A digital input triggers the start function.
[1] Bus A serial communication port or the eldbus
triggers the start function.
[2] Logic AND The eldbus/serial communication port and a
digital input trigger the start function.
[3] * Logic OR The eldbus/serial communication port or a
digital input trigger the start function.
8-54 Reversing Select
Option: Function:
Select the trigger for the reversing function.
[0] Digital
input
A digital input triggers the reversing function.
[1] Bus A serial communication port or the eldbus
triggers the reversing function.
[2] Logic AND The eldbus/serial communication port and a
digital input trigger the reversing function.
[3] * Logic OR The eldbus/serial communication port or a
digital input trigger the reversing function.
8-55 Set-up Select
Option: Function:
Select the trigger for the set-up selection.
[0] Digital
input
A digital input triggers the set-up selection.
[1] Bus A serial communication port or the eldbus
triggers the set-up selection.
[2] Logic AND The eldbus/serial communication port and a
digital input trigger the set-up selection.
[3] * Logic OR The eldbus/serial communication port or a
digital input trigger the set-up selection.
Parameter Descriptions Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 73
4 4
