3-95 Ramp Delay
Range: Function:
1000
ms*
[0 -
3600000 ms]
Enter the delay required from activation
of the digital potentiometer function
until the frequency converter starts to
ramp the reference. With a delay of 0 ms,
the reference starts to ramp as soon as
increase/decrease is activated.
3-96 Maximum Limit Switch Reference
Range: Function:
25 %* [0 -
200 %]
Enter the maximum limit switch reference. If
the crane reaches a limit switch (OFF), and if
the speed exceeds the value in this parameter,
then the speed is reduced automatically to the
value in this parameter. If the limit switch is
o, the speed cannot exceed the value in this
parameter.
Parameter Descriptions
VLT
®
Midi Drive FC 280
48 Danfoss A/S © 03/2016 All rights reserved. MG07C202
