![Danfoss VLT Midi Drive FC-280P4K0 [59/136] 4 relay](/img/pdf.png)
Danfoss VLT Midi Drive FC-280P4K0 [59/136] 4 relay
![Danfoss VLT Midi Drive FC-280P15K [59/136] 4 relay](/views2/1557234/page59/bg3b.png)
[160] No alarm The output is high when no alarm is
present.
[161] Running
reverse
The output is high when the frequency
converter is running counterclockwise
(the logical product of the status bits
Running AND Reverse).
[165] Local reference
active
[166] Remote ref
active
[167] Start command
active
The output is high when there is an
active start command, and no stop
command is active.
[168] Drive in hand
mode
The output is high when the frequency
converter is in hand-on mode.
[169] Drive in auto
mode
The output is high when the frequency
converter is in auto-on mode.
[170] Homing
Completed
The homing operation is completed. This
option is only eective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[171] Target Position
Reached
The target position is reached. This
option is only eective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[172] Position
Control Fault
A fault occurred in the positioning
process. Refer to parameter 37-18 Pos. Ctrl
Fault Reason for details about the fault.
This option is only eective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[173] Position Mech
Brake
Selects mechanical control for positioning.
This option is only eective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[190] STO function
active
[193] Sleep mode The frequency converter/system has
entered sleep mode. See parameter group
22-4* Sleep Mode.
[194] Broken belt A broken-belt condition has been
detected. See parameter group 22-4* Sleep
Mode.
[239] STO function
fault
5-30 Terminal 27 Digital Output
Option: Function:
[0] * No operation
5-34 On Delay, Digital Output
Range: Function:
0.01 s* [0 - 600 s]
5-35 O Delay, Digital Output
Range: Function:
0.01 s* [0 - 600 s]
4.6.3 5-4* Relay
Parameters for conguring the timing and the output
functions for the relay.
The parameter shows 1 relay.
5-40 Function Relay
Option: Function:
[0] No operation Default setting for all digital outputs.
[1] * Control Ready The control card is ready.
[2] Drive ready The frequency converter is ready to
operate. Mains and control supplies are
OK.
[3] Drive rdy/rem ctrl The frequency converter is ready for
operation, and in auto-on mode.
[4] Stand-by / no
warning
Ready for operation. No start or stop
commands have been applied. No
warnings are active.
[5] Running The motor runs, and a shaft torque is
present.
[6] Running / no
warning
The output speed is higher than the
speed set in parameter 1-82 Min Speed
for Function at Stop [Hz]. The motor is
running and no warnings are present.
[7] Run in range/no
warn
The motor runs within the
programmed current ranges set in
parameter 4-50 Warning Current Low.
[8] Run on ref/no
warn
The motor runs at reference speed. No
warnings.
[9] Alarm An alarm activates the output. No
warnings.
[10] Alarm or warning An alarm or warning activates the
output.
[11] At torque limit The torque limit set in
parameter 4-16 Torque Limit Motor
Mode or parameter 4-17 Torque Limit
Generator Mode has been exceeded.
[12] Out of current
range
The motor current is outside the range
set in parameter 4-18 Current Limit.
[13] Below current,
low
The motor current is lower than set in
parameter 4-50 Warning Current Low.
[14] Above current,
high
The motor current is higher than set in
parameter 4-51 Warning Current High.
[15] Out of frequency
range
The output speed/frequency exceeds
the limit that is set in
parameter 4-40 Warning Freq. Low and
parameter 4-41 Warning Freq. High.
[16] Below frequency,
low
The output frequency is lower than the
setting in parameter 4-40 Warning Freq.
Low.
[17] Above frequency,
high
The frequency is higher than the
setting in parameter 4-41 Warning Freq.
High.
Parameter Descriptions Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 57
