4-50 Warning Current Low
Range: Function:
0 A* [ 0 - 194.0
A]
Enter the I
LOW
value. When the motor current
drops below this limit, a bit in the status word
is set. This value can also be programmed to
produce a signal on the digital output or the
relay output.
4-51 Warning Current High
Range: Function:
Size
related*
[ 0.0 -
194.0 A]
Enter the I
HIGH
value. When the motor
current exceeds this limit, a bit in the
status word is set. This value can also be
programmed to produce a signal on the
digital output or the relay output.
4-54 Warning Reference Low
Range: Function:
-4999* [-4999 -
4999 ]
Enter the low reference limit. When the actual
reference drops below this limit, the display
shows Ref
LOW
. Bit 20 is set in
parameter 16-94 Ext. Status Word. The output
relay or the digital output can be congured
to indicate this warning. The LCP warning
light is not turned on when this parameter set
limit is reached.
4-55 Warning Reference High
Range: Function:
4999* [-4999 -
4999 ]
Use this parameter to set a high limit for the
reference range. When the actual reference
exceeds this limit, the display shows Ref
HIGH
. Bit
19 is set in parameter 16-94 Ext. Status Word.
The output relay or the digital output can be
congured to indicate this warning. The LCP
warning light is not turned on when this
parameter set limit is reached.
4-56 Warning Feedback Low
Range: Function:
-4999
ProcessCtrlUnit*
[-4999 - 4999
ProcessCtrlUnit]
Use this parameter to set a
low limit for the feedback
range. When the feedback
drops below this limit, the
display shows Feedb Low. Bit
6 is set in
parameter 16-94 Ext. Status
Word. The output relay or the
digital output can be
congured to indicate this
warning. The LCP warning
light is not turned on when
this parameter set limit is
reached.
4-57 Warning Feedback High
Range: Function:
4999
ProcessCtrlUnit*
[-4999 - 4999
ProcessCtrlUnit]
Use this parameter to set a
high limit for the feedback
range. When the feedback
exceeds this limit, the display
reads Feedb High. Bit 5 is set
in parameter 16-94 Ext. Status
Word. The output relay or the
digital output can be
congured to indicate this
warning. The LCP warning
light is not turned on when
this parameter set limit is
reached.
4-58 Missing Motor Phase Function
Option: Function:
[0] O No alarm is shown if a missing motor phase occurs.
[1] * On An alarm is shown if a missing motor phase occurs.
4-61 Bypass Speed From [Hz]
Range: Function:
0 Hz* [ 0 - 500
Hz]
Some systems call for avoiding certain
output speeds due to resonance problems
in the system. Enter the lower limits of the
speeds to be avoided.
4-63 Bypass Speed To [Hz]
Range: Function:
0 Hz* [ 0 - 500
Hz]
Some systems call for avoiding certain
output speeds due to resonance problems
in the system. Enter the upper limits of the
speeds to be avoided.
4-64 Semi-Auto Bypass Set-up
Option: Function:
[0] * O
[1] Enable
Parameter Descriptions Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 51
4 4
