Danfoss VLT Midi Drive FC-280P4K0 [119/136] Drive information
![Danfoss VLT Midi Drive FC-280P4K0 [119/136] Drive information](/views2/1557234/page119/bg77.png)
14-30
Current Lim Ctrl, Proportional
Gain 100 % All set-ups TRUE 0 Uint16
14-31 Current Lim Ctrl, Integration Time 0.020 s All set-ups TRUE -3 Uint16
14-32 Current Lim Ctrl, Filter Time 5 ms All set-ups TRUE -4 Uint16
14-4* Energy Optimising
14-40 VT Level 66 % All set-ups FALSE 0 Uint8
14-41 AEO Minimum Magnetisation 66 % All set-ups FALSE 0 Uint8
14-44
d-axis current optimization for
IPM 100 % All set-ups TRUE 0 Uint8
14-5* Environment
14-50 RFI Filter [2] Grid Type 1 set-up FALSE - Uint8
14-51 DC-Link Voltage Compensation [1] On All set-ups FALSE - Uint8
14-52 Fan Control
[5] Constant-on
mode 1 set-up TRUE - Uint8
14-55 Output Filter [0] No Filter 1 set-up FALSE - Uint8
14-6* Auto Derate
14-61 Function at Inverter Overload [0] Trip All set-ups TRUE - Uint8
14-63 Min Switch Frequency [2] 2.0 kHz 1 set-up FALSE - Uint8
14-64
Dead Time Compensation Zero
Current Level [0] Disabled All set-ups FALSE - Uint8
14-65
Speed Derate Dead Time
Compensation Size Related All set-ups FALSE 0 Uint16
14-8* Options
14-89 Option Detection
[0] Protect Option
Cong. 1 set-up TRUE - Uint8
14-9* Fault Settings
14-90 Fault Level [3] Trip Lock All set-ups TRUE - Uint8
5.2.15 15-** Drive Information
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
15-0* Operating Data
15-00 Operating hours 0 h 1 set-up TRUE 74 Uint32
15-01 Running Hours 0 h 1 set-up TRUE 74 Uint32
15-02 kWh Counter 0 kWh 1 set-up TRUE 75 Uint32
15-03 Power Up's 0 N/A 1 set-up TRUE 0 Uint32
15-04 Over Temp's 0 N/A 1 set-up TRUE 0 Uint16
15-05 Over Volt's 0 N/A 1 set-up TRUE 0 Uint16
15-06 Reset kWh Counter [0] Do not reset 1 set-up TRUE - Uint8
15-07 Reset Running Hours Counter [0] Do not reset 1 set-up TRUE - Uint8
15-3* Alarm Log
15-30 Alarm Log: Error Code 0 N/A 1 set-up TRUE 0 Uint8
15-31 InternalFaultReason 0 N/A 1 set-up TRUE 0 Int16
15-4* Drive Identication
15-40 FC Type 0 N/A 1 set-up FALSE 0 VisStr[7]
15-41 Power Section 0 N/A 1 set-up FALSE 0 VisStr[20]
15-42 Voltage 0 N/A 1 set-up FALSE 0 VisStr[20]
15-43 Software Version 0 N/A 1 set-up FALSE 0 VisStr[20]
15-44 Ordered TypeCode 0 N/A 1 set-up FALSE 0 VisStr[41]
15-45 Actual Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
15-46 Drive Ordering No 0 N/A 1 set-up FALSE 0 VisStr[9]
15-48 LCP Id No 0 N/A 1 set-up FALSE 0 VisStr[21]
15-49 SW ID Control Card 0 N/A 1 set-up FALSE 0 VisStr[21]
