7-31 Process PID Anti Windup
Option: Function:
[0] O Continues regulation of an error even when the
output frequency cannot be increased or decreased.
[1] * On Ceases regulation of an error when the output
frequency can no longer be adjusted.
7-32 Process PID Start Speed
Range: Function:
0 RPM* [0 -
6000
RPM]
Enter the motor speed to be attained as a
start signal for commencement of PID
control. When the power is switched on, the
frequency converter starts to ramp and then
operates under speed open-loop control.
When the process PID start speed is reached,
the frequency converter changes to process
PID control.
7-33 Process PID Proportional Gain
Range: Function:
0.01* [0 - 10] Enter the PID proportional gain. The proportional
gain multiplies the error between the setpoint
and the feedback signal.
7-34 Process PID Integral Time
Range: Function:
9999 s* [0.10 -
9999 s]
Enter the PID integral time. The integrator
provides an increasing gain at a constant
error between the setpoint and the
feedback signal. The integral time is the
time needed by the integrator to reach the
same gain as the proportional gain.
7-35 Process PID Dierentiation Time
Range: Function:
0 s* [0 - 20 s] Enter the PID dierentiation time. The dieren-
tiator does not react to a constant error, but
provides a gain only when the error changes.
The shorter the PID dierentiation time, the
stronger the gain from the dierentiator.
7-36 Process PID Di. Gain Limit
Range: Function:
5* [1 - 50] Enter a limit for the dierentiator gain. If there is
no limit, the dierentiator gain increases when
there are fast changes. To obtain a pure dieren-
tiator gain at slow changes and a constant
dierentiator gain where fast changes occur, limit
the dierentiator gain.
7-38 Process PID Feed Forward Factor
Range: Function:
0 %* [0 -
200 %]
Enter the PID feed forward (FF) factor. The FF
factor sends a constant fraction of the reference
signal to bypass the PID control, so the PID
control only aects the remaining fraction of the
control signal. Any change to this parameter
aects the motor speed. When the FF factor is
activated, it provides less overshoot, and high
dynamics when changing the setpoint.
Parameter 7-38 Process PID Feed Forward Factor is
active when parameter 1-00 Conguration Mode
is set to [3] Process.
7-39 On Reference Bandwidth
Range: Function:
5 %* [0 -
200 %]
Enter the on-reference bandwidth. When the
PID control error (the dierence between the
reference and the feedback) is less than the
value of this parameter, the on-reference
status bit is 1.
7-40 Process PID I-part Reset
Option: Function:
[0] * No
[1] Yes Select [1] Yes to reset the I-part of the process PID
controller. The selection automatically returns to [0]
No. Resetting the I-part makes it possible to start from
a well-dened point after changing something in the
process, for example changing a textile roll.
7-41 Process PID Output Neg. Clamp
Range: Function:
-100 %* [ -100 - 100 %] Enter a negative limit for the process
PID controller output.
7-42 Process PID Output Pos. Clamp
Range: Function:
100 %* [ -100 - 100 %] Enter a positive limit for the process
PID controller output.
7-43 Process PID Gain Scale at Min. Ref.
Range: Function:
100 %* [0 -
100 %]
Enter a scaling percentage to apply to the
process PID output when operating at the
minimum reference. The scaling percentage is
adjusted linearly between the scale at
minimum reference (parameter 7-43 Process PID
Gain Scale at Min. Ref.) and the scale at
maximum reference (parameter 7-44 Process
PID Gain Scale at Max. Ref.).
Parameter Descriptions
VLT
®
Midi Drive FC 280
68 Danfoss A/S © 03/2016 All rights reserved. MG07C202
