Danfoss VLT Midi Drive FC-280P4K0 [118/136] Smart logic control
![Danfoss VLT Midi Drive FC-280P2K2 [118/136] Smart logic control](/views2/1557234/page118/bg76.png)
5.2.13 13-** Smart Logic Control
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
13-0* SLC Settings
13-00 SL Controller Mode [0] O 1 set-up TRUE - Uint8
13-01 Start Event
[39] Start
command 1 set-up TRUE - Uint8
13-02 Stop Event [40] Drive stopped 1 set-up TRUE - Uint8
13-03 Reset SLC
[0] Do not reset
SLC 1 set-up TRUE - Uint8
13-1* Comparators
13-10 Comparator Operand [0] Disabled 1 set-up TRUE - Uint8
13-11 Comparator Operator
[1] Approx.Equal
(~) 1 set-up TRUE - Uint8
13-12 Comparator Value 0 N/A 1 set-up TRUE -3 Int32
13-2* Timers
13-20 SL Controller Timer 0 s 1 set-up TRUE -2 Uint32
13-4* Logic Rules
13-40 Logic Rule Boolean 1 [0] False 1 set-up TRUE - Uint8
13-41 Logic Rule Operator 1 [0] Disabled 1 set-up TRUE - Uint8
13-42 Logic Rule Boolean 2 [0] False 1 set-up TRUE - Uint8
13-43 Logic Rule Operator 2 [0] Disabled 1 set-up TRUE - Uint8
13-44 Logic Rule Boolean 3 [0] False 1 set-up TRUE - Uint8
13-5* States
13-51 SL Controller Event [0] False 1 set-up TRUE - Uint8
13-52 SL Controller Action [0] Disabled 1 set-up TRUE - Uint8
5.2.14 14-** Special Functions
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
14-0* Inverter Switching
14-01 Switching Frequency Size Related All set-ups TRUE - Uint8
14-03 Overmodulation [1] On All set-ups FALSE - Uint8
14-07 Dead Time Compensation Level Size Related All set-ups FALSE 0 Uint8
14-08 Damping Gain Factor Size Related All set-ups TRUE 0 Uint8
14-09 Dead Time Bias Current Level Size Related All set-ups FALSE 0 Uint8
14-1* Mains On/O
14-10 Mains Failure [0] No function All set-ups FALSE - Uint8
14-11 Mains Voltage at Mains Fault Size Related All set-ups TRUE 0 Uint16
14-12 Function at Mains Imbalance [0] Trip 1 set-up TRUE - Uint8
14-15 Kin. Backup Trip Recovery Level Size Related All set-ups TRUE -3 Uint32
14-2* Reset Functions
14-20 Reset Mode [0] Manual reset All set-ups TRUE - Uint8
14-21 Automatic Restart Time 10 s All set-ups TRUE 0 Uint16
14-22 Operation Mode
[0] Normal
operation 1 set-up TRUE - Uint8
14-24 Trip Delay at Current Limit 60 s All set-ups TRUE 0 Uint8
14-25 Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
14-27 Action At Inverter Fault [1] Warning All set-ups TRUE - Uint8
14-28 Production Settings [0] No action 1 set-up FALSE - Uint8
14-29 Service Code 0 N/A 1 set-up TRUE 0 Uint32
14-3* Current Limit Ctrl.
Parameter Lists
VLT
®
Midi Drive FC 280
116 Danfoss A/S © 03/2016 All rights reserved. MG07C202
