1 Introduction
1.1 How to Read This Programming Guide
1.1.1 Purpose of the Manual
This programming guide provides information about
controlling the frequency converter, accessing parameters,
programming, and troubleshooting.
The programming guide is intended for use by
qualied
personnel who are familiar with the VLT
®
Midi Drive FC
280 frequency converter.
Read the instructions before programming and follow the
procedures in this manual.
VLT
®
is a registered trademark.
1.1.2 Additional Resources
Additional resources include:
•
VLT
®
Midi Drive FC 280 Operating Guide, provides
the necessary information for getting the
frequency converter up and running.
•
VLT
®
Midi Drive FC 280 Design Guide, provides
detailed technical information about the
frequency converter, customer design, and
applications.
•
VLT
®
Midi Drive FC 280 Service Guide, provides
information to Danfoss authorized, qualied
technicians on how to service the FC 280
frequency converters.
Contact the local Danfoss supplier or go to
drives.danfoss.com/knowledge-center/technical-documen-
tation/ to download the documentations.
1.1.3 Document and Software Version
This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition Remarks Software
version
MG07C2 Update due to new software
version release.
1.1
Table 1.1 Document and Software Version
AC Alternating current
AEO Automatic energy optimization
ACP Application control processor
AWG American wire gauge
AMA Automatic motor adaptation
°C
Degrees Celsius
DC Direct current
EEPROM
Electrically erasable programmable
read-only memory
EMC Electromagnetic compatibility
EMI Electromagnetic interference
ETR Electronic thermal relay
f
M,N
Nominal motor frequency
FC Frequency converter
IP Ingress protection
I
LIM
Current limit
I
INV
Rated inverter output current
I
M,N
Nominal motor current
I
VLT,MAX
Maximum output current
I
VLT,N
Rated output current supplied by the
frequency converter
L
d
Motor d-axis inductance
L
q
Motor q-axis inductance
LCP Local control panel
MCP Motor control processor
N.A. Not applicable
P
M,N
Nominal motor power
PCB Printed circuit board
PE Protective earth
PELV Protective extra low voltage
PWM Pulse width modulated
R
s
Stator resistance
Regen Regenerative terminals
RPM Revolutions per minute
RFI Radio frequency interference
SCR Silicon controlled rectier
SMPS Switch mode power supply
T
LIM
Torque limit
U
M,N
Nominal motor voltage
X
h
Motor main reactance
Table 1.2 Abbreviations
Introduction Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 3
1 1
