Danfoss VLT Midi Drive FC-280P4K0 [120/136] Data readouts
![Danfoss VLT Midi Drive FC-280P11K [120/136] Data readouts](/views2/1557234/page120/bg78.png)
15-50 SW ID Power Card 0 N/A 1 set-up FALSE 0 VisStr[21]
15-51 Drive Serial Number 0 N/A 1 set-up FALSE 0 VisStr[13]
15-52 OEM Information 0 N/A 1 set-up FALSE 0 VisStr[40]
15-53 Power Card Serial Number 0 N/A 1 set-up FALSE 0 VisStr[21]
15-57 File Version 0 N/A 1 set-up FALSE 0 Uint8
15-59 Filename 0 N/A 1 set-up FALSE 0 VisStr[16]
15-6* Option Ident
15-60 Option Mounted Size Related All set-ups FALSE 0 VisStr[30]
15-61 Option SW Version Size Related All set-ups FALSE 0 VisStr[20]
15-70 Option in Slot A 0 N/A All set-ups FALSE 0 VisStr[30]
15-71 Slot A Option SW Version 0 N/A All set-ups FALSE 0 VisStr[20]
15-9* Parameter Info
15-92 Dened Parameters 0 N/A 1 set-up TRUE 0 Uint16
15-97 Application Type 0 N/A 1 set-up TRUE 0 Uint32
15-98 Drive Identication 0 N/A 1 set-up FALSE 0 VisStr[56]
15-99 Parameter Metadata 0 N/A 1 set-up FALSE 0 Uint16
5.2.16 16-** Data Readouts
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
16-0* General Status
16-00 Control Word 0 N/A 1 set-up TRUE 0 Uint16
16-01 Reference [Unit]
0 ReferenceFeed-
backUnit 1 set-up TRUE -3 Int32
16-02 Reference [%] 0 % 1 set-up TRUE -1 Int16
16-03 Status Word 0 N/A 1 set-up TRUE 0 Uint16
16-05 Main Actual Value [%] 0 % 1 set-up TRUE -2 Int16
16-09 Custom Readout
0 CustomRea-
doutUnit 1 set-up TRUE -2 Int32
16-1* Motor Status
16-10 Power [kW] 0 kW 1 set-up TRUE -3 Uint32
16-11 Power [hp] 0 hp 1 set-up TRUE -3 Uint32
16-12 Motor Voltage 0 V 1 set-up TRUE -1 Uint32
16-13 Frequency 0 Hz 1 set-up TRUE -1 Uint32
16-14 Motor current 0 A 1 set-up TRUE -2 Uint16
16-15 Frequency [%] 0 % 1 set-up TRUE -1 Uint16
16-16 Torque [Nm] 0 Nm All set-ups FALSE -1 Int32
16-18 Motor Thermal 0 % 1 set-up TRUE 0 Uint8
16-20 Motor Angle 0 N/A All set-ups TRUE 0 Uint16
16-22 Torque [%] 0 % All set-ups FALSE 0 Int16
16-3* Drive Status
16-30 DC Link Voltage 0 V 1 set-up TRUE 0 Uint32
16-33 Brake Energy /2 min 0 kW All set-ups FALSE 0 Uint32
16-34 Heatsink Temp. 0 °C 1 set-up TRUE 100 Int8
16-35 Inverter Thermal 0 % 1 set-up TRUE 0 Uint8
16-36 Inv. Nom. Current 0 A 1 set-up TRUE -2 Uint16
16-37 Inv. Max. Current 0 A 1 set-up TRUE -2 Uint16
16-38 SL Controller State 0 N/A 1 set-up TRUE 0 Uint8
16-39 Control Card Temp. 0 °C All set-ups FALSE 100 Uint16
16-5* Ref. & Feedb.
16-50 External Reference 0 % 1 set-up TRUE -1 Int16
16-52 Feedback[Unit] 0 ProcessCtrlUnit 1 set-up TRUE -3 Int32
16-53 Digi Pot Reference 0 N/A All set-ups FALSE -2 Int16
Parameter Lists
VLT
®
Midi Drive FC 280
118 Danfoss A/S © 03/2016 All rights reserved. MG07C202
