5.2.21 32-** Motion Control Basic Settings
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
32-11 User Unit Denominator 1 N/A 1 set-up FALSE 0 Uint32
32-12 User Unit Numerator 1 N/A 1 set-up FALSE 0 Uint32
32-67 Max. Tolerated Position Error 2000000 N/A 1 set-up TRUE 0 Uint32
32-80 Maximum Allowed Velocity 1500 RPM 1 set-up FALSE 67 Uint16
32-81 Motion Ctrl Quick Stop Ramp 1000 ms 1 set-up TRUE -3 Uint32
5.2.22 33-** Motion Control Adv. Settings
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
33-00 Homing Mode [0] Not forced 1 set-up TRUE - Uint8
33-01 Home Oset 0 N/A 1 set-up TRUE 0 Int32
33-02 Home Ramp Time 10 ms 1 set-up TRUE -3 Uint16
33-03 Homing Velocity 100 RPM 1 set-up TRUE 67 Int16
33-04 Homing Behaviour
[1] Reverse no
index 1 set-up TRUE - Uint8
33-41 Negative Software Limit -500000 N/A 1 set-up TRUE 0 Int32
33-42 Positive Software Limit 500000 N/A 1 set-up TRUE 0 Int32
33-43 Negative Software Limit Active [0] Inactive 1 set-up TRUE - Uint8
33-44 Positive Software Limit Active [0] Inactive 1 set-up TRUE - Uint8
33-47 Target Position Window 0 N/A 1 set-up TRUE 0 Uint16
5.2.23 34-** Motion Control Data Readouts
Parameter # Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
34-0* PCD Write Par.
34-01 PCD 1 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-02 PCD 2 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-03 PCD 3 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-04 PCD 4 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-05 PCD 5 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-06 PCD 6 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-07 PCD 7 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-08 PCD 8 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-09 PCD 9 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-10 PCD 10 Write For Application 0 N/A All set-ups TRUE 0 Uint16
34-2* PCD Read Par.
34-21 PCD 1 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-22 PCD 2 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-23 PCD 3 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-24 PCD 4 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-25 PCD 5 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-26 PCD 6 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-27 PCD 7 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-28 PCD 8 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-29 PCD 9 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-30 PCD 10 Read For Application 0 N/A All set-ups TRUE 0 Uint16
34-5* Process Data
34-50 Actual Position 0 N/A All set-ups TRUE 0 Int32
Parameter Lists Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 121
