5-40 Function Relay
Option: Function:
the output goes high. Otherwise, it
goes low.
[63] Comparator 3 See parameter group 13-1* Smart Logic
Control. If comparator 3 in SLC is TRUE,
the output goes high. Otherwise, it
goes low.
[64] Comparator 4 See parameter group 13-1* Smart Logic
Control. If comparator 4 in SLC is TRUE,
the output goes high. Otherwise, it
goes low.
[65] Comparator 5 See parameter group 13-1* Smart Logic
Control. If comparator 5 in SLC is TRUE,
the output goes high. Otherwise, it
goes low.
[70] Logic rule 0 See parameter group 13-4* Logic Rules.
If logic rule 0 in SLC is TRUE, the
output goes high. Otherwise, it goes
low.
[71] Logic rule 1 See parameter group 13-4* Logic Rules.
If logic rule 1 in SLC is TRUE, the
output goes high. Otherwise, it goes
low.
[72] Logic rule 2 See parameter group 13-4* Logic Rules.
If logic rule 2 in SLC is TRUE, the
output goes high. Otherwise, it goes
low.
[73] Logic rule 3 See parameter group 13-4* Logic Rules.
If logic rule 3 in SLC is TRUE, the
output goes high. Otherwise, it goes
low.
[74] Logic rule 4 See parameter group 13-4* Logic Rules.
If logic rule 4 in SLC is TRUE, the
output goes high. Otherwise, it goes
low.
[75] Logic rule 5 See parameter group 13-4* Logic Rules.
If logic rule 5 in SLC is TRUE, the
output goes high. Otherwise, it goes
low.
[80] SL digital output
A
See parameter 13-52 SL Controller
Action. Output A is low on [32] Smart
Logic Action. Output A is high on [38]
Smart Logic Action.
[81] SL digital output
B
See parameter 13-52 SL Controller
Action. Output B is low on [32] Smart
Logic Action. Output B is high on [38]
Smart Logic Action.
[82] SL digital output
C
See parameter 13-52 SL Controller
Action. Output C is low on [32] Smart
Logic Action. Output C is high on [38]
Smart Logic Action.
[83] SL digital output
D
See parameter 13-52 SL Controller
Action. Output D is low on [32] Smart
Logic Action. Output D is high on [38]
Smart Logic Action.
5-40 Function Relay
Option: Function:
[160] No alarm The output is high when no alarm is
present.
[161] Running reverse The output is high when the frequency
converter is running counterclockwise
(the logical product of the status bits
Running AND Reverse).
[165] Local ref active
[166] Remote ref active
[167] Start command
activ
The output is high when there is an
active start command, and no stop
command is active.
[168] Drive in hand
mode
The output is high when the frequency
converter is in hand-on mode.
[169] Drive in auto
mode
The output is high when the frequency
converter is in auto-on mode.
[170] Homing
Completed
The homing operation is completed.
This option is only eective when
parameter 37-00 Application Mode is set
to [2] Position Control.
[171] Target Position
Reached
The target position is reached. This
option is only eective when
parameter 37-00 Application Mode is set
to [2] Position Control.
[172] Position Control
Fault
A fault occurred in the positioning
process. Refer to parameter 37-18 Pos.
Ctrl Fault Reason for details about the
fault. This option is only eective when
parameter 37-00 Application Mode is set
to [2] Position Control.
[173] Position Mech
Brake
Selects mechanical control for
positioning. This option is only
eective when
parameter 37-00 Application Mode is set
to [2] Position Control.
[190] STO function
active
[193] Sleep Mode The frequency converter/system has
entered sleep mode. See parameter
group 22-4* Sleep Mode.
[194] Broken Belt
Function
A broken-belt condition has been
detected. See parameter group 22-4*
Sleep Mode.
[239] STO Function
Fault
5-41 On Delay, Relay
Range: Function:
0.01 s* [0.01 -
600 s]
Enter the delay of the relay cut-in time. The
relay only cuts in if the condition in
parameter 5-40 Function Relay is uninter-
rupted during the specied time.
Parameter Descriptions Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 59
