14-90 Fault Level
Use this parameter to customize fault levels. Use the 8
th
element
to control the fault level of alarm 13, Overcurrent.
Option: Function:
[3] * Trip Lock Alarm is set to trip-lock.
[4] Trip w.
delayed reset
Alarm is congured into trip alarm, which
can be reset after a delay time. For
example, if alarm 13, Overcurrent is
congured to this option, it can be reset 3
minutes after the alarm.
[5] Flystart At start-up, the frequency converter tries to
catch a spinning motor. If this option is
selected, parameter 1-73 Flying Start is
forced to [1] Enabled.
Index Alarm Trip lock Trip w.
delayed
Flystart
0 Reserved
1 Reserved
2 Reserved
3 Reserved
4 Reserved
5 Reserved
6 Reserved
7 Overcurrent D x x
Table 4.5 Table for Selection of Action when
Selected Alarm Appears (Parameter 14-90 Fault Level)
D=Default setting
x=Possible selection
Parameter Descriptions Programming Guide
MG07C202 Danfoss A/S © 03/2016 All rights reserved. 87
4 4
