English
Chapter 2 Server System Overview
is chapter provides diagrams showing the location of important components of
the server system.
2.1 System Components
2 x Power Supply Units
8 x 3.5” HDD Carriers
4 x 2.5” PCIE SSD Carriers
4 x System Fans
1 x VGA Port
Top Covers
Server Board
Riser Card Assembly
Front Controls and Indicators
