ASRock 2U4FH-8L [24/43] Installing a hard disk drive into 2 hard drive carrier
![ASRock 2U4FH-8L [24/43] Installing a hard disk drive into 2 hard drive carrier](/views2/1694126/page24/bg18.png)
18 19
English
3.2.2 Installing a Hard Disk Drive into 2.5" Hard Drive Carrier
e system supports 2.5" PCIE SSDs.
Removing 2.5” SSD Carriers from the Chassis
1. Remove the screws that secures the SSD carrier.
