2U4FH-8L
36 37
English
Hot Plug Detection
Header
(4-pin HS_DET_1)
1
GND
PV_VCCIO
SMB_CPU_PCIE_CLK
SMB_CPU_PCIE_DTA
e header is used for PCIE
Hot Swap for Purley.
SSD Signal Connectors
(PE_SSD0)
(PE_ SSD1)
ese connectors are used
to connect a SSD signal
cable to the SDDs.
