2U4FH-8L
30 31
English
11. Power Cable, ATX 12Pin to 4*4Pin (Quantity: 1)
PDB
BPB
12. 2.5" SSD Cables, SATA 7+15 to 7Pin+1*4Pin (650mm) (Quantity: 2)
BPB
PCIE SSD Add-in CardSSD
13. 2.5" SSD Cables, SATA 7+15 to 7Pin+1*4Pin (800mm) (Quantity: 2)
BPB
PCIE SSD Add-in CardSSD
Connections and cable routing may dier depending on various server boards. Please refer
to the Quick Installation Guide to know the exact headers or connectors to be connected on
the server board you purchase. For more detailed information about server board compo-
nents, refer to the manual that comes with your server board.
