6 7
English
No. Item
1 Server Board (SB)
2 Riser Card Assembly
3
Add-in Card Slots: 2 x PCIE Add-in Cards (on the riser card assembly)*
Mezzanine Slot: 1 x Storage Mezzanine Card (on the server board)**
4
Add-in Card Slots: 2 x PCIE Add-in Cards (on the riser card assembly)*
Mezzanine Slot: 1 x LAN Mezzanine Card (on the server board)**
5 Power Supply Unit (PSU2)
6 Power Supply Unit (PSU1)
7 4 x Power Distribution Boards (PDB)
8 System Fan (FAN1)
9 System Fan (FAN2)
10 System Fan (FAN3)
11 System Fan (FAN4)
12 HDD Backplane Board (BPB)
13 2.5” SSD Carrier (SSD0)
14 2.5” SSD Carrier (SSD1)
15 2.5” SSD Carrier (SSD2)
16 2.5” SSD Carrier (SSD3)
17 Front Panel Board (FPB)
18 VGA Port
19 8 x 3.5'' Hot-Swap HDD Trays (HDD0~HDD7)
*Supports Low prole and FHHL (Full High Half Length) PCIe cards
**Supports 1GbE x 2, 10GbE x2 or SFP+ (Fiber) mezzaine cards (M350R/M540R/M599R/M599RS)
