ASRock 2U4FH-8L [26/43] English
![ASRock 2U4FH-8L [26/43] English](/views2/1694126/page26/bg1a.png)
20 21
English
3.3 Power Supply
e system can accommodate two AC or two DC power supplies in the bay at the rear of
the chassis. Each unit provides up to 750 Watts of power. Only a single power supply is
required for operation, with the second power supply purely as a redundant, load-sharing
backup. It can be removed without aecting system operation.
Removing the Power Supply Unit
To remove a failed power supply, please rst identify the failed power supply .
1. Hold onto the power supply handle while pressing the locking lever towards the power
supply handle.
2. Pull to remove the power supply from the chassis.
2
1
1
2
1. Before replacing the power supply, power o the server, unplug the power cord, and
disconnect all wiring from the power supply.
2. In a redundant system, you do not need to power down the server.
