2U4FH-8L
10 11
English
Chapter 3 Hardware Installation and
Maintenance
is chapter helps you assemble the chassis and install components.
Before You Begin
Before you work with the server, pay close attention to the “Important Safety Instructions”
at the beginning of this manual.
1. Make sure the server is powered o.
Power down the server if it is still running.
(1) Press the Power button to power o the server from full-power mode to standby-
power (sleep) mode. e Power LED at the front turns from solid green to blinking
green.
(2) Disconnect the power cord rst from the AC outlet and then from the server.
e power LED turns o.
2. Ensure you have a clean and stable working environment. Avoid dust and dirt because
contaminants may cause malfunctions.
3. Ground yourself properly before touching any system component. A discharge of static
electricity may damage components. Wear a grounded wrist strap if available.
Installing Procedures
e followings are prerequisite to be installed.
•
3.5" HDD(s) or or 2.5" SSD(s)
•
Power Supplies (Pre-installed)
•
Server Board (Pre-installed)
•
Front Panel Board (Pre-installed)
•
HDD Backplanes (Pre-installed)
•
Power Distribution Boards (Pre-installed)
•
Fans (Pre-installed)
Up to four add-in cards are optional to be installed when you have a riser board installed
on your server board.
e server is not completely powered down when you press the Power button on the front
panel. e Power button lets the server toggle between Power On and Standby (Sleep)
modes. Some internal circuitry remain active in the Standby mode. To remove all power
from the system completely, be sure to disconnect the power cord from the server.
1. Some components are already pre-installed. Simply properly connect the relavant cables
before or aer installation. See the Quick Installation Guide for more details.
2. Refer to the user manual of the server board you use for instructions on how to install
server board components.
