ESIEN05-04 Wiring Diagrams
Part 1 – System Outline 1–87
3
1
4
5
A1P Printed circuit board infrared remote control (Receiver/display unit)
A2P Printed circuit board (Transformer 230V/16V) A3P Printed circuit board
C1 Capacitor (M1F) A4P Printed circuit board
HAP Light emitting diode (Service monitor-green) BS1 Push button (ON/OFF)
KAR Magnetic relay (M1S) H1P Light emitting diode (on-red)
KPR Magnetic relay (M1P) H2P Light emitting diode (timer-green)
M1F Motor (Indoor fan) H3P Light emitting diode (filter sign-red)
M1S Motor (Swing flap) H4P Light emitting diode (defrost-orange)
Q1M Thermo switch (M1F embedded) SS1 Selector switch (Main/Sub)
R1T Thermistor (Air) SS2 Selector switch (Wireless address set)
R2T Thermistor (Coil)
S1Q Limit switch (Swing flap) Connector for optional parts
SS1 Selector switch (Emergency) X15A Connector (Float switch)
V1TR Phase control circuit X25A Connector (Drain pump)
X1M Terminal block X35A Connector (Group control adapter)
X2M Terminal block X60A, X61A Connector (Interface adapter for Sky Air series)
RC Signal receiver circuit
TC Signal transmission circuit Wired remote control
R1T Thermistor (Air)
SS1 Selector switch (Main/Sub)
