ESIEN05-04 Specifications
Part 1 – System Outline 1–47
3
1
4
5
2.3 FCQ – D
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FCQ71DV3B FCQ100DV3B FCQ125DV3B FCQ140DV3B
Heat exchanger Rows x stages x fin pitch 2 x 10 x 1.2 mm 2 x 12 x 1.2 mm
Face area 0.454 m² 0.544 m²
Tube type Hi-XSS
Fin type Multi louver fin
Fan Air flow rate cooling (high) 19 m³/min 30 m³/min
Air flow rate cooling (low) 14 m³/min 21 m³/min 24 m³/min 25 m³/min
Air flow rate heating (high)
Air flow rate heating (low)
Qty x model (rotor) 1 x QTS46F15M 1 x QTS46E17M
Qty x model (motor) 1 x
EHDS50B30DK
(inverter)
1 x
EHDS10B120DK
(inverter)
Fan speed 2
Fan type Turbo fan
Refrigerant Type R410A
Safety and functional devices _
Air filter Resin net (with mold resistant) - in decoration panel
Temperature control Microcomputer control
Weight Unit 24 kg 28 kg
Specification FCQ71DV3B FCQ100DV3B FCQ125DV3B FCQ140DV3B
Unit Phase 1~
Voltage 230V
Frequency 50 Hz
Nominal running current _
Fan motor FLA (Full Load Amps) 0.30 A 0.70 A
No. of motors x output 1 x 30 W 1 x 120 W
