General Outline ESIEN05-04

1–32 Part 1 – System Outline

1.16 FUQ71B

Outlook and

dimensions

The illustration below shows the outlook and the dimensions of the unit (mm).

Suspension bolt

Suspension position

Drain

connection

location for

upwards piping

*Drain pipe can

be raised up to 350mm from the top surface of the product.

*When closing the

discharge grill, the

required space is 30mm

or more. (Note 3)

or more*

NOTES:

1. Location of unit’s name plate: on bell mouth.

2.In case of using infrared remote control, this is the position for the

signal receiver. Refer to the drawing of infrared remote control for

detail.

3. When closing the discharge grill (2 or 3 way discharge), direction of

pipe connecion will be limited, please refer to Installation manual.)

or more*

Height of suspension bracket

or more

(Required space)

Drain

connection

location for rear

piping

Required space

Brand name plate ( Note 2)
