Specifications ESIEN05-04
1–48 Part 1 – System Outline
3
11
4
5
2.4 FFQ – B
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FFQ25B7V1B FFQ35B7V1B FFQ50B7V1B FFQ60B7V1B
Heat exchanger Rows x stages x fin pitch 2x10x1.5 mm
Face area 0.269 m²
Tube type HiXSS diam. 7
Fin type Multi louver fin
Fan Air flow rate cooling (high) 9.0 m³/min 10.0 m³/min 12.0 m³/min 15.0 m³/min
Air flow rate cooling (low) 6.5 m³/min 6.5 m³/min 8.0 m³/min 10.0 m³/min
Air flow rate heating (high) 9.0 m³/min 10.0 m³/min – 15.0 m³/min
Air flow rate heating (low) 6.5 m³/min 6.5 m³/min – 10.0 m³/min
Qty x model (rotor) 1 x QTS32C15M
Qty x model (motor) 1 x D16P52A23
Fan speed 2 steps
Fan type Turbo fan
Refrigerant Type R410A
Safety and functional devices Inline fuse (250V 5A)
Fan motor thermal protector
OFF: 130
+/- 5
°C
ON: 83
+/- 20
°C
Air filter Removable/washable/mildew proof/long life (in decoration panel)
Temperature control Microcomputer control
Weight Unit 17.5 kg
Specification FFQ25B7V1B FFQ35B7V1B FFQ50B7V1B FFQ60B7V1B
Unit Phase 1~
Voltage 230V
Frequency 50 Hz
Power consumption 73 W 84 W 97 W 120 W
Nominal running current 0.37 A 0.40 A 0.49 A 0.61 A
Fan motor FLA (Full Load Amps) 0.60 A 0.70 A
No. of motors x output 1 x 55 W
