ESIEN05-04 Specifications
Part 1 – System Outline 1–49
3
1
4
5
2.5 FBQ – B
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FBQ35B7V1 FBQ50B7V1 FBQ60B7V1 FBQ71B7V3B FBQ100B7V3B FBQ125B7V3B
Heat exchanger Rows x stages x fin pitch 3 x 14 x 1.75 mm
Face area 0.132 m² 0.221 m² 0.338 m²
Tube type HI-XA diam. 7 Hi-XSS diam. 7
Fin type Rhombus
Fan Air flow rate cooling (high) 11.5 m³/min 14.0 m³/min 19.0 m³/min 19.0 m³/min 27.0 m³/min 35.0 m³/min
Air flow rate cooling (low) 9.0 m³/min 10.0 m³/min 14.0 m³/min 14.0 m³/min 20.0 m³/min 24.0 m³/min
Air flow rate heating (high) 11.5 m³/min 14.0 m³/min 19.0 m³/min 19.0 m³/min 27.0 m³/min 35.0 m³/min
Air flow rate heating (low) 9.0 m³/min 10.0 m³/min 14.0 m³/min 14.0 m³/min 20.0 m³/min 24.0 m³/min
Qty x model (rotor) 1 x QD18G3BM 2 x QD18G2BM 3 x QD18G2BM
Qty x model (motor) 1 x CA-0513D 1 x CA-0514D 1 x CA-0515SEK 1 x A37P135G20
Fan speed 2 steps (direct drive) 3 steps (direct drive)
Fan type Sirocco
Refrigerant Type R410A
Safety and functional devices Inline fuse (250V 5A) _
Fan motor thermal fuse 152
+/-2
°C
Air filter Resin net (with mold resistant)
Temperature control Computerized control Microprocessor thermostat for cooling and heating
Weight Unit 30 kg 31 kg 41 kg 41 kg 51 kg 52 kg
Specification FBQ35B7V1 FBQ50B7V1 FBQ60B7V1 FBQ71B7V3B FBQ100B7V3B FBQ125B7V3B
Unit Phase 1~
Voltage 230 V
Frequency 50Hz
Power consumption _
Nominal running current _
Fan motor FLA (Full Load Amps) 0.5 A 0.7 A 0.9 A 1.0 A
No. of motors x output 1 x 65 W 1 x 85 W 1 x 125 W 1 x 125 W 1 x 135 W 1 x 225 W
