ESIEN05-04 Wiring Diagrams
Part 1 – System Outline 1–63
3
1
4
5
33H Float switch Wired remote control
A1P Printed circuit board SS1 Selector switch (Main/Sub)
C1R Capacitor (M2F)
F1U Fuse (5A, 250V) Receiver/display unit (attached to infrared remote control)
HAP Light emitting diode (Service monitor-green) A2P, A3P Printed circuit board
M1A Motor (Swing flap) BS ON/OFF button
M2F Motor (Indoor fan) H1P Light emitting diode (on-red)
M3P Motor (Drain pump) H2P Light emitting diode (timer-green)
Q1F Thermo switch (M2F embedded) H3P Light emitting diode (filter sign-red)
R1T Thermistor (Air) H4P Light emitting diode (defrost-orange)
R2T Thermistor (Liquid) SS1 Selector switch (Main/Sub)
R3T Thermistor (Coil) SS2 Selector switch (Wireless address set)
RyP Magnetic relay (M3P)
SS1 Selector switch (Emergency) adapter for wiring
T1R Transformer (220V~240V/22 V) RyC, RyF Magnetic relay
X1M Terminal strip (Power)
X2M Terminal strip (Control) Connector for optional parts
PC Phase control circuit X60A, X61A Connector (Interface adapter for Sky Air series)
RC Signal receiver circuit X33A Connector (adapter for wiring)
TC Signal transmission circuit X35A Connector (Group control adapter)
X40A Connector (Remote ON/OFF, Forced OFF)
