Capacity Tables (Heat Pump High COP Series) ED34-645B
590 RXYQ-PH
Heating capacity
Combin-
ation (%)
(Capacity
index)
Outdoor
air temp.
Indoor air temp. °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
70
(424)
-19.8 -20.0 47.3 18.5 47.2 18.9 47.1 19.4 47.1 19.6 47.0 19.8 45.8 19.5
-18.8 -19.0 48.7 18.7 48.6 19.1 48.6 19.6 48.5 19.8 48.5 20.0 45.8 18.7
-16.7 -17.0 51.6 19.2 51.5 19.6 51.4 20.0 50.8 19.8 49.1 19.0 45.8 17.5
-13.7 -15.0 54.5 19.6 54.4 19.9 52.5 19.3 50.8 18.5 49.1 17.8 45.8 16.3
-11.8 -13.0 57.4 19.9 55.9 19.5 52.5 18.1 50.8 17.4 49.1 16.7 45.8 15.3
-9.8 -11.0 59.2 19.7 55.9 18.3 52.5 17.0 50.8 16.4 49.1 15.7 45.8 14.5
-9.5 -10.0 59.2 19.1 55.9 17.8 52.5 16.5 50.8 15.9 49.1 15.3 45.8 14.1
-8.5 -9.1 59.2 18.6 55.9 17.4 52.5 16.1 50.8 15.5 49.1 14.9 45.8 13.7
-7.0 -7.6 59.2 17.9 55.9 16.7 52.5 15.5 50.8 14.9 49.1 14.3 45.8 13.2
-5.0 -5.6 59.2 16.9 55.9 15.8 52.5 14.7 50.8 14.2 49.1 13.6 45.8 12.6
-3.0 -3.7 59.2 16.2 55.9 15.1 52.5 14.0 50.8 13.5 49.1 13.0 45.8 12.0
0.0 -0.7 59.2 15.1 55.9 14.1 52.5 13.1 50.8 12.6 49.1 12.2 45.8 11.3
3.0 2.2 59.2 14.1 55.9 13.2 52.5 12.3 50.8 11.9 49.1 11.5 45.8 10.6
5.0 4.1 59.2 13.6 55.9 12.7 52.5 11.9 50.8 11.5 49.1 11.0 45.8 10.2
7.0 6.0 59.2 13.1 55.9 12.3 52.5 11.4 50.8 11.0 49.1 10.6 45.8 9.9
9.0 7.9 59.2 12.6 55.9 11.8 52.5 11.0 50.8 10.7 49.1 10.3 45.8 9.5
11.0 9.8 59.2 12.2 55.9 11.4 52.5 10.7 50.8 10.3 49.1 10.0 45.8 9.2
13.0 11.8 59.2 11.8 55.9 11.0 52.5 10.3 50.8 10.0 49.1 9.6 45.8 8.9
15.0 13.7 59.2 11.4 55.9 10.7 52.5 10.0 50.8 9.7 49.1 9.3 45.8 8.69
60
(363)
-19.8 -20.0 47.1 19.6 47.0 20.0 45.0 19.1 43.6 18.3 42.1 17.6 39.2 16.2
-18.8 -19.0 48.5 19.8 47.9 19.8 45.0 18.4 43.6 17.7 42.1 17.0 39.2 15.6
-16.7 -17.0 50.8 19.8 47.9 18.4 45.0 17.1 43.6 16.5 42.1 15.8 39.2 14.6
-13.7 -15.0 50.8 18.5 47.9 17.2 45.0 16.0 43.6 15.4 42.1 14.8 39.2 13.7
-11.8 -13.0 50.8 17.4 47.9 16.2 45.0 15.1 43.6 14.5 42.1 13.9 39.2 12.9
-9.8 -11.0 50.8 16.4 47.9 15.3 45.0 14.2 43.6 13.7 42.1 13.2 39.2 12.2
-9.5 -10.0 50.8 15.9 47.9 14.8 45.0 13.8 43.6 13.3 42.1 12.8 39.2 11.8
-8.5 -9.1 50.8 15.5 47.9 14.5 45.0 13.5 43.6 13.0 42.1 12.5 39.2 11.6
-7.0 -7.6 50.8 14.9 47.9 13.9 45.0 13.0 43.6 12.5 42.1 12.0 39.2 11.1
-5.0 -5.6 50.8 14.2 47.9 13.2 45.0 12.3 43.6 11.9 42.1 11.5 39.2 10.6
-3.0 -3.7 50.8 13.5 47.9 12.7 45.0 11.8 43.6 11.4 42.1 11.0 39.2 10.2
0.0 -0.7 50.8 12.6 47.9 11.8 45.0 11.1 43.6 10.7 42.1 10.3 39.2 9.6
3.0 2.2 50.8 11.9 47.9 11.1 45.0 10.4 43.6 10.1 42.1 9.7 39.2 9.0
5.0 4.1 50.8 11.4 47.9 10.7 45.0 10.1 43.6 9.7 42.1 9.4 39.2 8.72
7.0 6.0 50.8 11.0 47.9 10.4 45.0 9.7 43.6 9.4 42.1 9.1 39.2 8.43
9.0 7.9 50.8 10.7 47.9 10.0 45.0 9.4 43.6 9.1 42.1 8.77 39.2 8.16
11.0 9.8 50.8 10.3 47.9 9.7 45.0 9.1 43.6 8.79 42.1 8.49 39.2 7.91
13.0 11.8 50.8 10.0 47.9 9.4 45.0 8.80 43.6 8.51 42.1 8.23 39.2 7.67
15.0 13.7 50.8 9.7 47.9 9.1 45.0 8.54 43.6 8.26 42.1 7.99 39.2 7.45
50
(303)
-19.8 -20.0 42.3 17.7 39.9 16.5 37.5 15.34 36.3 14.8 35.1 14.2 32.7 13.1
-18.8 -19.0 42.3 17.1 39.9 15.9 37.5 14.8 36.3 14.3 35.1 13.7 32.7 12.7
-16.7 -17.0 42.3 15.9 39.9 14.9 37.5 13.8 36.3 13.3 35.1 12.8 32.7 11.9
-13.7 -15.0 42.3 14.9 39.9 13.9 37.5 13.0 36.3 12.5 35.1 12.1 32.7 11.2
-11.8 -13.0 42.3 14.0 39.9 13.1 37.5 12.2 36.3 11.8 35.1 11.4 32.7 10.5
-9.8 -11.0 42.3 13.2 39.9 12.4 37.5 11.6 36.3 11.2 35.1 10.8 32.7 10.0
-9.5 -10.0 42.3 12.9 39.9 12.1 37.5 11.3 36.3 10.9 35.1 10.5 32.7 9.7
-8.5 -9.1 42.3 12.6 39.9 11.8 37.5 11.0 36.3 10.6 35.1 10.3 32.7 9.5
-7.0 -7.6 42.3 12.1 39.9 11.4 37.5 10.6 36.3 10.3 35.1 9.9 32.7 9.2
-5.0 -5.6 42.3 11.5 39.9 10.8 37.5 10.1 36.3 9.8 35.1 9.5 32.7 8.8
-3.0 -3.7 42.3 11.0 39.9 10.4 37.5 9.7 36.3 9.4 35.1 9.1 32.7 8.43
0.0 -0.7 42.3 10.4 39.9 9.7 37.5 9.1 36.3 8.8 35.1 8.53 32.7 7.94
3.0 2.2 42.3 9.8 39.9 9.2 37.5 8.63 36.3 8.35 35.1 8.07 32.7 7.52
5.0 4.1 42.3 9.4 39.9 8.9 37.5 8.33 36.3 8.06 35.1 7.80 32.7 7.28
7.0 6.0 42.3 9.1 39.9 8.58 37.5 8.06 36.3 7.80 35.1 7.55 32.7 7.05
9.0 7.9 42.3 8.81 39.9 8.30 37.5 7.81 36.3 7.56 35.1 7.32 32.7 6.84
11.0 9.8 42.3 8.54 39.9 8.05 37.5 7.57 36.3 7.34 35.1 7.10 32.7 6.64
13.011.842.38.2739.97.8037.57.3436.37.1235.16.8932.76.45
15.013.742.38.0339.97.5837.57.1436.36.9235.16.7032.76.28
TC Total capacity ; kW
PI Power Input ; kW(Comp.+Outdoor fan motor)
Note1: is shown as reference.
When selecting the unit models, avoid the Outdoor air temperature range shown by .
Note2: The above table shows the average value of conditions which may occur.
