Daikin RXYQ28PY1 [268/487] Rxyq14py1
![Daikin RXYQ5PY1 [268/487] Rxyq14py1](/views2/1711913/page268/bg10c.png)
Field Wiring ED34-645B
660 Installation of Outdoor Units
The above table indicates power specifications for standard combinations (see 2. INTRODUCTION).
If using anything other than the above combinations like PH Series in a multi system, calculate using the following
procedure.
Minimum circuit amp value: add the minimum circuit amp values for each independent unit
Recommended fuse capacity: select the fuse capacity with the next higher value of the calculated minimum circuit
amp. multiplied by 1.1.
Ex: Combining the RXYQ30PHY1 using RXYQ8PY1, RXYQ10PY1, and RXYQ12PY1.
Minimum circuit amp. of the RXYQ8PY1 in table above = 18.5 A
Minimum circuit amp. of RXYQ10PY1 in table above = 21.6 A
Minimum circuit amp. of RXYQ12PY1 in table above = 22.7 A
Accordingly, the minimum circuit amp. of the RXYQ30PHY1 = 18.5 + 21.6 + 22.7= 62.8 A
Multiplying the result above by 1.1 (62.8 × 1.1) = 69.1 A, so the recommended fuse capacity would be 70 A.
50Hz ( ): High COP Series
Model Name
Phase and
frequency
Voltage
Minimum circuit amp.
Recommended fuses
Normal High COP Normal
High
COP
Normal High COP
RXYQ5PY1
φ
3, 50Hz
380-415V 11.9A 15A
RXYQ8PY1
φ
3, 50Hz
380-415V 18.5A 25A
RXYQ10PY1
φ
3, 50Hz
380-415V 21.6A 25A
RXYQ12PY1
φ
3, 50Hz
380-415V 22.7A 25A
RXYQ14PY1
φ
3, 50Hz
380-415V 31.5A 35A
RXYQ16PY1 (RXYQ16PHY1)
φ
3, 50Hz
380-415V 31.5A (37.0A) 35A (50A)
RXYQ18PY1 (RXYQ18PHY1)
φ
3, 50Hz
380-415V 32.5A (40.1A) 40A (50A)
RXYQ20PY1
φ
3, 50Hz
380-415V 41.2A 50A
RXYQ22PY1
φ
3, 50Hz
380-415V 44.3A 50A
RXYQ24PY1 (RXYQ24PHY1)
φ
3, 50Hz
380-415V 50.0A (55.5A) 60A (70A)
RXYQ26PY1 (RXYQ26PHY1)
φ
3, 50Hz
380-415V 51.0A (58.6A) 60A (70A)
RXYQ28PY1 (RXYQ28PHY1)
φ
3, 50Hz
380-415V 54.1A (59.7A) 60A (70A)
RXYQ30PY1 (RXYQ30PHY1)
φ
3, 50Hz
380-415V 55.2A (62.8A) 70A (70A)
RXYQ32PY1 (RXYQ32PHY1)
φ
3, 50Hz
380-415V 63.0A (63.9A) 70A (80A)
RXYQ34PY1 (RXYQ34PHY1)
φ
3, 50Hz
380-415V 64.0A (67.0A) 80A (80A)
RXYQ36PY1 (RXYQ36PHY1)
φ
3, 50Hz
380-415V 65.0A (68.1A) 80A (80A)
RXYQ38PY1 (RXYQ38PHY1)
φ
3, 50Hz
380-415V 73.7A (76.9A) 90A (90A)
RXYQ40PY1 (RXYQ40PHY1)
φ
3, 50Hz
380-415V 81.5A (76.9A) 90A (90A)
RXYQ42PY1 (RXYQ42PHY1)
φ
3, 50Hz
380-415V 82.5A (77.9A) 100A (90A)
RXYQ44PY1 (RXYQ44PHY1)
φ
3, 50Hz
380-415V 83.5A (85.7A) 100A (100A)
RXYQ46PY1 (RXYQ46PHY1)
φ
3, 50Hz
380-415V 86.6A (86.7A) 100A (100A)
RXYQ48PY1 (RXYQ48PHY1)
φ
3, 50Hz
380-415V 87.7A (94.5A) 100A (110A)
RXYQ50PY1 (RXYQ50PHY1)
φ
3, 50Hz
380-415V 96.5A (95.5A) 110A (110A)
RXYQ52PY1
φ
3, 50Hz
380-415V 96.5A 110A
RXYQ54PY1
φ
3, 50Hz
380-415V 97.5A 110A
Note
