Capacity Tables (Heat Pump High COP Series) ED34-645B
606 RXYQ-PH
Heating capacity
Combin-
ation (%)
(Capacity
index)
Outdoor
air temp.
Indoor air temp. °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
70
(707)
-19.8 -20.0 75.8 32.4 75.6 33.2 75.5 34.1 75.4 34.5 75.3 34.9 75.2 35.7
-18.8 -19.0 77.2 32.7 77.0 33.5 76.9 34.3 76.8 34.7 76.7 35.1 76.3 35.7
-16.7 -17.0 80.2 33.3 80.1 34.1 79.9 34.8 79.9 35.2 79.8 35.6 76.3 34.0
-13.7 -15.0 83.7 33.9 83.5 34.6 83.4 35.4 83.3 35.7 81.9 35.2 76.3 32.3
-11.8 -13.0 87.4 34.5 87.3 35.2 87.1 35.9 84.7 34.7 81.9 33.3 76.3 30.6
-9.8 -11.0 91.5 35.0 91.4 35.7 87.5 34.1 84.7 32.8 81.9 31.5 76.3 28.9
-9.5 -10.0 93.7 35.3 93.1 35.8 87.5 33.1 84.7 31.9 81.9 30.6 76.3 28.1
-8.5 -9.1 95.7 35.6 93.1 34.8 87.5 32.3 84.7 31.0 81.9 29.8 76.3 27.4
-7.0 -7.6 98.7 35.7 93.1 33.3 87.5 30.9 84.7 29.7 81.9 28.5 76.3 26.3
-5.0 -5.6 99 33.6 93.1 31.3 87.5 29.1 84.7 28.0 81.9 26.9 76.3 24.8
-3.0 -3.7 99 31.7 93.1 29.5 87.5 27.4 84.7 26.4 81.9 25.4 76.3 23.4
0.0 -0.7 99 28.9 93.1 26.9 87.5 25.1 84.7 24.2 81.9 23.3 76.3 21.5
3.0 2.2 99 26.4 93.1 24.7 87.5 23.0 84.7 22.2 81.9 21.4 76.3 19.8
5.0 4.1 99 24.9 93.1 23.3 87.5 21.8 84.7 21.0 81.9 20.3 76.3 18.8
7.0 6.0 99 23.6 93.1 22.1 87.5 20.6 84.7 19.9 81.9 19.2 76.3 17.8
9.0 7.9 99 22.3 93.1 20.9 87.5 19.5 84.7 18.9 81.9 18.2 76.3 16.9
11.0 9.8 99 21.1 93.1 19.8 87.5 18.5 84.7 17.9 81.9 17.3 76.3 16.1
13.0 11.8 99 20.0 93.1 18.8 87.5 17.6 84.7 17.0 81.9 16.4 76.3 15.3
15.0 13.7 99 19.0 93.1 17.8 87.5 16.7 84.7 16.2 81.9 15.6 76.3 14.5
60
(606)
-19.8 -20.0 75.4 34.5 75.3 35.2 75.0 35.8 72.6 34.4 70.2 33.0 65.4 30.3
-18.8 -19.0 76.8 34.7 76.7 35.4 75.0 35.0 72.6 33.6 70.2 32.3 65.4 29.7
-16.7 -17.0 79.9 35.2 79.7 35.9 75.0 33.3 72.6 32.1 70.2 30.8 65.4 28.3
-13.7 -15.0 83.3 35.7 79.8 34.1 75.0 31.7 72.6 30.4 70.2 29.3 65.4 26.9
-11.8 -13.0 84.6 34.7 79.8 32.3 75.0 30.0 72.6 28.9 70.2 27.7 65.4 25.5
-9.8 -11.0 84.6 32.8 79.8 30.5 75.0 28.4 72.6 27.3 70.2 26.3 65.4 24.2
-9.5 -10.0 84.6 31.8 79.8 29.7 75.0 27.6 72.6 26.6 70.2 25.5 65.4 23.6
-8.5 -9.1 84.6 31.0 79.8 28.9 75.0 26.9 72.6 25.9 70.2 24.9 65.4 23.0
-7.0 -7.6 84.6 29.7 79.8 27.7 75.0 25.8 72.6 24.8 70.2 23.9 65.4 22.1
-5.0 -5.6 84.6 27.9 79.8 26.1 75.0 24.3 72.6 23.4 70.2 22.6 65.4 20.9
-3.0 -3.7 84.6 26.4 79.8 24.7 75.0 23.0 72.6 22.2 70.2 21.4 65.4 19.8
0.0 -0.7 84.6 24.1 79.8 22.6 75.0 21.1 72.6 20.4 70.2 19.6 65.4 18.2
3.0 2.2 84.6 22.2 79.8 20.8 75.0 19.4 72.6 18.8 70.2 18.1 65.4 16.8
5.0 4.1 84.6 21.0 79.8 19.7 75.0 18.4 72.6 17.8 70.2 17.2 65.4 16.0
7.0 6.0 84.6 19.9 79.8 18.7 75.0 17.5 72.6 16.9 70.2 16.3 65.4 15.2
9.0 7.9 84.6 18.9 79.8 17.7 75.0 16.6 72.6 16.1 70.2 15.5 65.4 14.5
11.0 9.8 84.6 17.9 79.8 16.8 75.0 15.8 72.6 15.3 70.2 14.8 65.4 13.8
13.0 11.8 84.6 17.0 79.8 16.0 75.0 15.0 72.6 14.5 70.2 14.0 65.4 13.1
15.0 13.7 84.6 16.1 79.8 15.2 75.0 14.3 72.6 13.8 70.2 13.4 65.4 12.5
50
(505)
-19.8 -20.0 70.5 33.2 66.5 31.0 62.5 28.8 60.5 27.7 58.5 26.6 54.5 24.5
-18.8 -19.0 70.5 32.5 66.5 30.3 62.5 28.1 60.5 27.1 58.5 26.1 54.5 24.0
-16.7 -17.0 70.5 31.0 66.5 28.9 62.5 26.9 60.5 25.9 58.5 24.9 54.5 23.0
-13.7 -15.0 70.5 29.4 66.5 27.5 62.5 25.6 60.5 24.6 58.5 23.7 54.5 21.9
-11.8 -13.0 70.5 27.9 66.5 26.1 62.5 24.3 60.5 23.4 58.5 22.5 54.5 20.8
-9.8 -11.0 70.5 26.4 66.5 24.7 62.5 23.0 60.5 22.2 58.5 21.4 54.5 19.8
-9.5 -10.0 70.5 25.7 66.5 24.0 62.5 22.4 60.5 21.6 58.5 20.8 54.5 19.3
-8.5 -9.1 70.5 25.1 66.5 23.4 62.5 21.9 60.5 21.1 58.5 20.3 54.5 18.8
-7.0 -7.6 70.5 24.0 66.5 22.5 62.5 21.0 60.5 20.3 58.5 19.5 54.5 18.1
-5.0 -5.6 70.5 22.7 66.5 21.3 62.5 19.9 60.5 19.2 58.5 18.5 54.5 17.2
-3.0 -3.7 70.5 21.5 66.5 20.2 62.5 18.9 60.5 18.2 58.5 17.6 54.5 16.3
0.0 -0.7 70.5 19.7 66.5 18.5 62.5 17.4 60.5 16.8 58.5 16.2 54.5 15.1
3.0 2.2 70.5 18.2 66.5 17.1 62.5 16.1 60.5 15.5 58.5 15.0 54.5 14.0
5.0 4.1 70.5 17.3 66.5 16.3 62.5 15.3 60.5 14.8 58.5 14.3 54.5 13.3
7.0 6.0 70.5 16.4 66.5 15.5 62.5 14.5 60.5 14.1 58.5 13.6 54.5 12.7
9.0 7.9 70.5 15.6 66.5 14.7 62.5 13.8 60.5 13.4 58.5 13.0 54.5 12.1
11.0 9.8 70.5 14.9 66.5 14.0 62.5 13.2 60.5 12.8 58.5 12.4 54.5 11.6
13.0 11.8 70.5 14.1 66.5 13.3 62.5 12.6 60.5 12.2 58.5 11.8 54.5 11.0
15.0 13.7 70.5 13.5 66.5 12.7 62.5 12.0 60.5 11.6 58.5 11.3 54.5 10.6
TC Total capacity ; kW
PI Power Input ; kW(Comp.+Outdoor fan motor)
Note1: is shown as reference.
When selecting the unit models, avoid the Outdoor air temperature range shown by .
Note2: The above table shows the average value of conditions which may occur.
