Specifications ED34-645B
408 RXYQ-P
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference : 0m.
4 The power input (PI) (Comp. + Outdoor Fan Motor) : Refer to P.451~525.
5 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as RXYQ5PY1E.
Model Name (Combination Unit) RXYQ54PY1(E)
Model Name (Independent Unit) RXYQ18PY1(E)+RXYQ18PY1(E)+RXYQ18PY1(E)
★
1 Cooling Capacity (19.5°CWB)
kcal / h 127,000
Btu / h 505,000
kW 148
★2 Cooling Capacity (19.0°CWB)
kW
147
★3 Heating Capacity
kcal / h 146,000
Btu / h 580,000
kW 170
Casing Color Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1680×1240×765)+(1680×1240×765)+(1680×1240×765)
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.53+10.53)+(13.72+10.53+10.53)+(13.72+10.53+10.53)
Number of Revolutions r.p.m (7980, 2900, 2900)+(7980, 2900, 2900)+(7980, 2900, 2900)
Motor Output×Number
of Units
kW ((3.0+4.5+4.5)×1)+((3.0+4.5+4.5)×1)+((3.0+4.5+4.5)×1)
Starting Method Soft Start
Fan
Type Propeller Fan
Motor Output kW (0.75×2)+(0.75×2)+(0.75×2)
Air Flow Rate m³/min 239+239+239
Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
19.1 (Brazing Connection)
Gas Pipe mm
φ
41.3 (Brazing Connection)
Product Mass (Machine Weight) kg 341+341+341
Safety Devices High Pressure Switch, Fan Driver Overload Protector, Over Current Relay, Inverter Overload Protector
Defrost Method Deicer
Capacity Control % 3~100
Refrigerant
Refrigerant Name R-410A
Charge kg 12.7+12.7+12.7
Control Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
