ED34-645B Sound Levels
RXYQ-PH 623
14
5. Sound Levels
Overall
(Note)
Sound level:
Anechoic chamber conversion value, measured at a point 1 m in front of the unit at a height of 1.5m.
During actual operation, these values are normally somewhat higher as a result of ambient conditions.
Please refer to page 535 concerning about the Band level of each module.
dBA dBA dBA
Power Supply
50/60Hz/380-415V
Power Supply
50/60Hz/380-415V
Power Supply
50/60Hz/380-415V
Model Model Model
RXYQ16PHY1, YL
60
RXYQ32PHY1, YL
64
RXYQ42PHY1, YL
66
RXYQ18PHY1, YL
61
RXYQ34PHY1, YL
64
RXYQ44PHY1, YL
65
RXYQ24PHY1, YL
62
RXYQ36PHY1, YL
65
RXYQ46PHY1, YL
66
RXYQ26PHY1, YL
62
RXYQ38PHY1, YL
65
RXYQ48PHY1, YL
65
RXYQ28PHY1, YL
63
RXYQ40PHY1, YL
65
RXYQ50PHY1, YL
66
RXYQ30PHY1, YL
63
