ED34-645B Control Devices
Control 773
16
4.6.3 Initial Settings for Central Control Equipment
1. Central Remote Controller
Leave the master control connector (X1A) connected.
(Connected when shipped from the factory)
The connector is to be connected to only 1 central line.
Operation control setting
Sets the priority ranking of control for the central remote controller and remote controller for indoor units.
Zone setting
Sets the zones when several groups are controlled as one group.
2. Unified ON/OFF Controller (No.s 1, 2, and 3 in the figure above)
Remove the master control connector (X1A).
Control range setting switch (DS1)
Sets the range of group No.s for each group of indoor units to be controlled by unified ON/OFF controllers no.1,2
and 3. 16 units (16 groups) can be set by 1 unified ON/OFF controller.
Control mode switch (DS2)
Sets priority ranking of control for unified ON/OFF controllers and remote controllers for indoor units. If using in
combination with a central remote controller, the central remote controllers control mode is given priority.
3. Schedule Timer
Leave the setting connector for individual use (X1A) disconnected. (Disconnected when shipped from the factory)
Control mode switch (SS2)
Sets the priority ranking of control for the schedule timer and remote controllers for indoor units. If using in
combination with a central remote controller, the central remote controllers control mode is given priority.
4.6.4 Group No. Setting for Central Control
1. Setting by Remote Controller for Indoor Units
Sets group No.s in local setting mode by remote controller. (Group No.s are 1-00
~
1-15, 2-00
~
2-15 up to 8-00
~
8-
15)
2. Adaptor PC Board Setting
Sets group No. setting switches RS1 and RS2 for central control on PC board when using an interface adaptor for
SkyAir series, or wiring adaptor for other air-conditioners.
RS1 (Upper): 1
~
4 (1
~
8 in case of interface adaptor for SkyAir Series)
RS2 (Lower): 0
~
F
