ED34-645B Control Devices
Control 765
16
4.5.3 Names and Functions of Operating Section (Fig. 1, 2)
3P124623-5C
1
UNIFIED OPERATION BUTTON “ ”
Press this button to perform the unified operation
regardless of the No. of programmed time.
2
UNIFIED STOP BUTTON “ ”
Press this button to perform the unified stop
regardless of the No. of programmed time.
3
OPERATION LAMP (RED)
The light turns on during the operation of the indoor
unit.
4
DISPLAY “ ” (TIME NO.)
Displays the time No. only when used in conjunction
with the central remote controller.
5
DISPLAY “PROGRAM START.”
(PROGRAMMING START)
The light turns on when the timer is programmed.
6
DISPLAY “
OFF ” (HOLIDAY SETTING)
Lights above the day of the week set as holiday. The
operation controlled by timer is not available on that
day.
7
DISPLAY “ — ” (SETTING OF DAYS OF A WEEK)
Flashes below the day of the week programmed.
8
DISPLAY “ ” (MALFUNCTION CODE)
Displays the contents of malfunction during the stop
due to malfunction.
9
DISPLAY “ ” (PRESENT TIME)
Displays the present day of the week and time.
10
DISPLAY “ ” (PROGRAMMED TIME OF
SYSTEM START)
Displays the time programmed to start.
11
DISPLAY “ ” (PROGRAMMED TIME OF
SYSTEM OFF)
Displays the time programmed to stop.
12
TIME NO. BUTTON “ ”
Press this button to select time No..
13
CLOCK ADJUSTING BUTTON “ ”
Press this button to set the present time.
14
PROGRAMMING START BUTTON “ ”
Press this button to set or check the No. of
programmed time. Press it again after you are
through with the program.
15
BUTTON FOR SELECTING DAYS OF A WEEK “
”
Press this button to select the day of the week.
16
HOUR/MINUTE BUTTON “ ”
Press this button to adjust the present time and the
programmed time.
17
TIMER ON BUTTON “ ”
Press this button to set the present time and the
programmed time.
18
HOLIDAY SETTING BUTTON “ ”
Press this button to set holidays.
19
BUTTON FOR COPYING PROGRAM OF
PREVIOUS DAY “ ”
Use this button to set the No. of programmed time
same as that of the previous day.
20
PROGRAM CANCELING BUTTON “ ”
Use this button to set the programmed time to
cancel. The display shows
“ – ; – – ”.
(Note)
1. Please note that all the displays in the figure appear
for explanation purpose or when the cover is open.
