95
12
SET MODE
■ Level set mode
SSSSBB TTxx TToonnee ((BBaassss))
This item adjusts the bass level of the transmit audio
tone in SSB mode from –5 dB to +5 dB in 1 dB steps.
0dB
0 dB (default)
SSSSBB TTxx TToonnee ((TTrreebbllee))
This item adjusts the treble level of the transmit audio
tone in SSB mode from –5 dB to +5 dB in 1 dB steps.
0dB
0 dB (default)
SSSSBB TTBBWW ((WWIIDDEE)) LL
These items set the transmission passband width for
wide setting by selecting the lower and higher fre-
quencies.
Lower freq. : 100 (default), 300 and 500 Hz
100
100 Hz (default)
SSSSBB TTBBWW ((WWIIDDEE)) HH
These items set the transmission passband width for
wide setting by selecting the lower and higher fre-
quencies.
Higher freq.: 2500, 2700 and 2900 Hz (default)
2900
2900 Hz (default)
SSSSBB TTBBWW ((MMIIDD)) LL
These items set the transmission passband width for
middle setting by selecting the lower and higher fre-
quencies.
Lower freq. : 100, 300 (default) and 500 Hz
300
300 Hz (default)
SSSSBB TTBBWW ((MMIIDD)) HH
These items set the transmission passband width for
middle setting by selecting the lower and higher fre-
quencies.
Higher freq.: 2500, 2700 (default) and 2900 Hz
2700
2700 Hz (default)
SSSSBB TTBBWW ((NNAARR)) LL
These items set the transmission passband width for
narrow setting by selecting the lower and higher fre-
quencies.
Lower freq. : 100, 300 and 500 Hz (default)
500
500 Hz (default)
