Icom IC-756PROIII [101/124] Level set mode
![Icom IC-756PROIII [101/124] Level set mode](/views2/1074410/page101/bg65.png)
96
12
SET MODE
■
Level set mode (continued)
SSSSBB TTBBWW ((NNAARR)) HH
These items set the transmission passband width for
narrow setting by selecting the lower and higher fre-
quencies.
Lower freq. : 2500 (default), 2700 and 2900 Hz
2500
2500 Hz (default)
MMoonniittoorr LLeevveell
This item adjusts the transmit IF signal monitor level
from 0% to 100% in 1% steps.
See p. 70 for details.
50%
50% (default)
SSiiddee TToonnee LLeevveell
This item adjusts the CW side tone level from 0% to
100% in 1% steps.
See p. 70 for details.
50%
50% (default)
BBeeeepp LLeevveell
This item adjusts the volume level for confirmation
beep tones from 0% to 100% in 1% steps. When
beep tones are turned OFF, this setting has no effect.
50%
50% (default)
BBeeeepp LLeevveell LLiimmiitt
This item allows you to set a maximum volume level
for confirmation beep tones. Confirmation beep tones
are linked to the [AF] control until a specified volume
level is reached — further rotation of the [AF] control
will not increase the volume of the beep tones.
OONN
Beep level is limited with
[AF] (default)
OOFFFF
Beep level is linked to [AF]
SSiiddee TToonnee LLeevveell LLiimmiitt
This item allows you to set a maximum volume level
for CW side tones. CW side tones are linked to the
[AF] control until a specified volume level is reached
— further rotation of the [AF] control will not increase
the volume of the CW side tones.
OONN
CW side tone level is limited
with [AF] (default)
OOFFFF
CW side tone level is linked
to [AF]
12
