Icom IC-756PROIII [111/124] Internal views

106

INTERNAL VIEWS

PA fuse (FGB 5 A)

PA unit

FILTER unit

Internal antenna

tuner

•Top view

BPF unit

PRE AMP unit

RF unit

PLL unit

Space for optional

voice synthesizer

(UT-102)

MAIN unit

Clock backup battery

DSP unit

SPCH

Optional voice

synthesizer level adj.

•Bottom view
