23
3
BASIC OPERATION
➥ Push [VFO/MEMO] to switch between VFO and
memory modes.
•“VFO” appears when VFO mode, or the selected mem-
ory channel number appears when memory mode is
selected beside the frequency readout.
•Pushing [VFO/MEMO] for 1 sec. transfers the contents
of the selected memory channel to VFO mode. (p. 80)
SFTSFT
0
FIL2FIL2
CWCW
TXTX
USBUSB
qr.qot.pp
14.100.0014.100.00
BPFBPF
1
VFOVFO
BWBW
500 500
SFTSFT
0
FIL2FIL2
USBUSB
TXTX
CWCW
qr.qpp.pp
14.195.0014.195.00
VFOVFO
1
BWBW
2.4k2.4k
ANTANT
1
METERMETER
PoPo
ANTANT
1
METERMETER
PoPo
qw:pp
12:00
qw:pp
12:00
“VFO” indicator
Memory channel number
[VFO/MEMO]
■ Selecting VFO/memory mode
➥ Push [MAIN/SUB] to select access to the main or
sub readout.
•The sub readout frequency is displayed in outline or
mesh font. The sub readout functions only during split
oeration or dualwatch.
[MAIN/SUB]
■ Main/Sub band selection
