VOICE RECORDER FUNCTIONS
■ Digital voice recorder
The transceiver has a total of 8 memory channels, 4
each for transmit and receive, of digital voice memo-
ries. A maximum message length of 15 sec. can be
recorded in each receive channel, and a total message
length of 90 sec. can be recorded in transmit channels.
Providing a transmission memory is very convenient
for repeated CQ and number transmissions at contest
times, as well as when making consecutive calls in
DX’pedition.
•Recording a received audio
q Push [EXIT/SET] several times to close a multi-
function screen, if necessary.
w Select the desired mode by pushing [SSB],
[CW/RTTY] or [AM/FM].
e Push [(F-2)VOICE] to call up the voice recorder
screen.
•If the transmit voice memory channel (T1–T4) appears,
push [(F-5)T/R] to select receive voice memory chan-
nel.
r Push the desired memory channel switch,
[(F-1)R1]– [(F-4)R4], for 1 sec. to start recording.
• “REC” flashes and the recording timer counts up.
•The operating frequency, mode and current time are
programmed as the memory names automatically.
• Previously recorded contents are cleared.
t Push the selected memory channel switch,
[(F-1)R1]– [(F-4)R4], again to stop recording.
• Recording is automatically terminated after 30 min.
IMPORTANT!
Push one of [(F-1)R1]–[(F-4)R4] to stop record-
ing before, or when 15 sec. has passed from the
start of recording.
The voice recorder memory records the 15 sec.
(max.) of audio before one of [(F-1)R1]–[(F-4)
R4] is pushed.
For example, when recording 20 sec. of audio,
the first 5 sec. audio will be over-recorded with
the last 5 sec., so that the total of audio
recorded is 15 sec. only.
y Push [EXIT/SET] twice to exit the voice memory
screen.
•Playing the recorded audio
q Push [EXIT/SET] several times to close a multi-
function screen, if necessary.
w Push [(F-2)VOICE] to call up the voice recorder
screen.
•If the transmit voice memory channel (T1–T4) appears,
push [(F-5)T/R] to select receive voice memory chan-
nel.
e Push the desired memory channel switch,
[(F-1)R1]– [(F-4)R4], momentarily to playback.
• “PLAY” appears.
r Push the selected memory channel switch,
[(F-1)R1]– [(F-4)R4], again to stop playback if de-
sired.
•Playback is terminated automatically when all of the
recorded contents in the channel are played, or after
15 sec.
t Push [EXIT/SET] twice to exit the voice memory
screen.
