SET MODE
SSccrreeeenn SSaavveerr FFuunnccttiioonn
This item sets the screen saver setting from 60 min,
30 min, 15 min and OFF.
6600 mmiinn
Screen saver function activates after 60 minute of inactivity.
(default)
3300 mmiinn
Screen saver function activates after 30 minute of inactivity.
1155 mmiinn
Screen saver function activates after 15 minute of inactivity.
OOFFFF
Screen saver function is OFF.
MMyy CCaallll
Your call sign, etc. can be displayed in the opening
screen when turning power ON. Up to 10 characters
can be programmed.
Capital letters, numerals, some symbols (– /
.
) and
spaces can be used.
q Push [EXIT/SET] several times to close a multi-
function screen, if necessary.
w Push [EXIT/SET] for 1 sec. then [(F-2)DISP] mo-
mentarily to select the display set mode screen.
e Push [(F-2)
ZZ
] several times to select the ‘My Call’
item.
r Push [(F-4)EDIT] to edit.
•Acursor appears and blinks.
t Input the desired character by rotating the tuning
dial or by pushing the band key for number input.
• Push [ABC] to select capital letters.
•Push [123] or [etc] to toggle numerals and symbols.
• Push [(F-1)
ΩΩ
] or [(F-2)
≈≈
] for cursor movement.
• Push [(F-3)DEL] to delete the selected character.
• Push [(F-4)SPACE] to input a space.
y Push [EXIT/SET] to input the set name.
• The cursor disappears.
u Push [EXIT/SET] to exit the set mode screen.
•Opening screen example
ja3yua
NOW CALIBRATING
DIGITAL SIGNAL PROCESSOR
PLEASE WAIT FOR 10sec.
ç
å
DELDEL
SPACESPACE WIDEWIDE
DISPLAY SET
123123
ABCABC
Character
group
keys
Selected
character
Bright(LCD) 50%
Horizon 4
Backlight(Switches) 8
DisplayType A
DisplayFont Basic1
MemoryName ON
MyCall _A3YUA
ABCABC
é
è
EDIT
WIDEWIDE
DISPLAY SET
VOXVOX
OFFOFF
COMPCOMP
OFFOFF
WIDEWIDE
AGCAGC
MIDMID
Bright(LCD) 50%
Horizon 4
Backlight(Switches) 8
DisplayType A
DisplayFont Basic1
MemoryName ON
MyCall JA3YUA
■
Display set mode (continued)
