13 | Troubleshooting
Installer reference guide
217
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
Error code Detailed error code Description
E8 00 OU: Power input overvoltage.
Please contact your dealer.
EA 00 OU: Cool/heat switchover
problem.
Please contact your dealer.
H0 00 OU: Voltage/current sensor
problem.
Please contact your dealer.
H3 00 OU: Malfunction of high
pressure switch (HPS)
Please contact your dealer.
H6 00 OU: Malfunction of position
detection sensor.
Please contact your dealer.
H8 00 OU: Malfunction of
compressor
input (CT) system.
Please contact your dealer.
H9 00 OU: Malfunction of outdoor
air thermistor.
Please contact your dealer.
F3 00 OU: Malfunction of discharge
pipe temperature.
Please contact your dealer.
F6 00 OU: Abnormal high pressure
in cooling.
Please contact your dealer.
FA 00 OU: Abnormal high pressure,
actuation of HPS.
Please contact your dealer.
JA 00 OU: Malfunction of high
pressure sensor.
Please contact your dealer.
J3 00 OU: Malfunction of discharge
pipe thermistor.
Please contact your dealer.
J6 00 OU: Malfunction of heat
exchanger thermistor.
Please contact your dealer.
