15 | Technical data
Installer reference guide
237
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
Country Country code
(EN437)
Gas category Default setting After conversion
to G25
After conversion
to G31
France FR II
2Esi3P
G20/G25
(20/25mbar)
— G31 (37mbar)
United Kingdom GB II
2H3P
G20 (20mbar) — G31 (37mbar)
Greece GR II
2H3P
G20 (20mbar) — G31 (37mbar)
Croatia HR II
2H3P
G20 (20mbar) — G31 (37mbar)
Hungary HU I
2H
G20 (25mbar) — —
Ireland IE II
2H3P
G20 (20mbar) — G31 (37mbar)
Italy IT II
2H3P
G20 (20mbar) — G31 (37mbar)
Lithuania LT II
2H3P
G20 (20mbar) — G31 (37mbar)
Latvia LV I
2H
G20 (20mbar) — —
Malta MT I
3P
— — G31 (30mbar)
Poland PL II
2E3P
G20 (20mbar) — G31 (37mbar)
Portugal PT II
2H3P
G20 (20mbar) — G31 (37mbar)
Slovenia SI II
2H3P
G20 (20mbar) — G31 (37mbar)
Slovakia SK II
2H3P
G20 (20mbar) — G31 (37mbar,
50mbar)
Romania RO II
2H3P
G20 (20mbar) — G31 (30mbar)
Turkey TR I
2H
G20 (20mbar) — —
Ukraine UA II
2H
G20 (20mbar) — —
