7 | Installation
Installer reference guide
99
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
X2M
X1M
A4P
A8P
X5M
S6S
S7S
S8S
S9S
a
a Installation of EKRP1AHTA is required.
2 Fix the cable with cable ties to the cable tie mountings.
7.11.17 To connect the safety thermostat (normally closed contact)
1 Connect the safety thermostat (normally closed) cable to the appropriate
terminals as shown in the illustration below.
30
31
X2M
X1M
3
4
X5M
S1S
2 Fix the cable with cable ties to the cable tie mountings.
