7 | Installation
Installer reference guide
90
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
CAUTION
Do NOT push or place redundant cable length in the unit.
NOTICE
More technical specifications of the different connections are indicated on the inside
of the indoor unit.
7.11.6 To connect the main power supply of the indoor unit
1 Connect the main power supply.
In case of normal kWh rate power supply
X2M
X1M
1
2
3
X5M
1 2 3
1 2 3
a
Legend: see illustration below.
In case of preferential kWh rate power supply
