15 | Technical data
Installer reference guide
236
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
Supplier Daikin Europe N.V.,
Zandvoordestraat 300,
BE-8400 Oostende, Belgium
Type designation EHYKOMB33AA*
Sound power level L
WA
dB 50
Declared load profile — — XL
Water heating energy efficiency class — — A
Annual electricity consumption AEC kWh 15
Annual fuel consumption AFC GJ 18
Water heating energy efficiency η
WH
% 84
Efficiency class controller — — II
Contribution to yearly efficiency — % 2,0
IMPORTANT
▪ Please read all instructions before fitting this appliance.
▪ This appliance is not intended for use of persons (including children) with diminished physical, sensory or
mental ability, or lack of experience and knowledge, unless supervised by, or instruction about the use of the
appliance by a person who is responsible for their safety.
▪ The appliance and installation should every year be inspected by a qualified installer and cleaned when
necessary.
▪ The appliance can be cleaned with a damp cloth. Do not use aggressive or abrasive cleaning or solvent.
15.7.3 Appliance category and supply pressure
Country Country code
(EN437)
Gas category Default setting After conversion
to G25
After conversion
to G31
Austria AU II
2H3P
G20 (20mbar) — G31 (50mbar)
Bosnia and
Herzegovina
BA II
2H3P
G20 (20mbar) — G31 (37mbar)
Belgium
(1)
BE I
2E(s)
, I
3P
G20/G25
(20/25mbar)
— —
Bulgaria BG II
2H3P
G20 (20mbar) — G31 (30mbar)
Switzerland CH I
2H
, II
2H3P
G20 (20mbar) — G31 (37mbar,
50mbar)
Cyprus CY I
2H
G20 (20mbar) — —
Czech Republic CZ II
2H3P
G20 (20mbar) — G31 (37mbar)
Germany DE II
2ELL3P
G20 (20mbar) G25 (20mbar) G31 (50mbar)
Denmark DK I
2H
G20 (20mbar) — —
Spain ES II
2H3P
G20 (20mbar) — G31 (37mbar)
(1)
Any modifications to the gas valve MUST be performed by a certified representative of the manufacturer. For more
information, contact your dealer.
