Daikin EHYHBX08AFV3 [55/252] Preparation
![Daikin EHYHBX08AFV3 [55/252] Preparation](/views2/1798413/page55/bg37.png)
6 | Preparation
Installer reference guide
55
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
Item Description Wires Maximum
running current
Optional equipment
7 3‑way valve 3 100mA
(b)
8 Domestic hot water tank
thermistor
2
(d)
9 Power supply for drain pan
heater
2
(b)
10 Room thermostat/heat
pump convector
3 or 4 100mA
(b)
11 Outdoor ambient
temperature sensor
2
(b)
12 Indoor ambient
temperature sensor
2
(b)
Field supplied components
13 Shut-off valve 2 100mA
(b)
14 Electricity meter 2
(b)
15 Domestic hot water pump 2
(b)
16 Alarm output 2
(b)
17 Changeover to external heat
source control
2
(b)
18 Space cool/heat operation
control
2
(b)
19 Power consumption digital
inputs
2 (per input signal)
(b)
20 Gas meter 2
(b)
21 Safety thermostat 2
(e)
(a) Refer to name plate on outdoor unit.
(b) Minimum cable section 0.75mm².
(c) Use the cable supplied with the boiler.
(d) The thermistor and connection wire (12m) are delivered with the domestic hot
water tank.
(e) Cable section 0.75mm² till 1.25mm²; maximum length: 50m. Voltage-free contact
shall ensure the minimum applicable load of 15VDC, 10mA.
(f) Cable section 0.75mm² till 1.25mm²; maximum length: 500m. Applicable for both
single user interface and dual user interface connection.
(g) Cable section 1.5mm
2
; maximum length: 50m.
NOTICE
More technical specifications of the different connections are indicated on the inside
of the indoor unit.
